CONFIGURATIONS
Configuration
Base Configurations
-
3-channel mono (see page 8.3)
-
2-channel mono (see page 8.5)
-
3-channel stereo (see page 8.6)
-
2-channel stereo (see page 8.8)
Electrical Options
On 3-channel (mono or stereo)
-
switching option (mono,see page 8.10; stereo, see page 8.12)
-
long cable option (see page 32)
-
switching + long cable option (see page 8.32)
-
audio option (mono, see page 8.14; stereo, see page 8.15)
On 2-channel (mono or stereo)
-
switching option (mono, see page 8.17; stereo, see page 8.19)
-
long cable option (see page 8.32)
-
switching + long cable option (see page 8.32)
-
audio option (mono, see page 8.21; stereo, see page 8.22)
Combination options
A combination of the electrical options is also possible, which gives the following possibilities :
On 3-channel (mono or stereo)
-
switching + audio option (mono, see page 8.24; stereo, see page 8.26)
-
long cable + audio option (see page 8.32)
-
switching + long cable + audio option (see page 8.32)
On 2-channel (mono or stereo)
-
switching + audio option (mono, see page 8.28; stereo, see page 8.30)
-
long cable + audio option (see page 8.32)
-
switching + long cable + audio option (see page 8.32)
Other Options
- Color of the screen frame (see page 8.32)
- Rugged
These options can be added to any combination.
R5976280 RC3300W 19072001
Configurations
