Silicon Graphics Reality Center Installation Manual page 58

Connection table internal connections RACK system
Connection no.
con1
con2
con3
con4
con5
con6
con7
con8
con9
con10
R5976280 RC3300W 19072001
From
Output BNC's VSE40
Output A Quad Splitter 1
Output B Quad Splitter 1
Output C Quad Splitter 1
Output A Quad Splitter 2
Output B Quad Splitter 2
Output RCVDS05 1
Output RCVDS05 2
Monitor output Magic 1
Monitor output Magic 2
To
Input Quad Splitter 1
Input 2 RCVDS05 1
Input 2 RCVDS05 2
Input 3 Quad Switcher
Input 3 RCVDS05 1
Input 3 RCVDS05 2
Input Magic 1
Input Magic 2
Input 1 Quad Switcher
Input 2 Quad Switcher
Cable
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
5 BNC to 5 BNC 0.6m 2 ft
Configurations
Order no.
Z348330
Z348330
Z348330
Z348330
Z348330
Z348330
Z348330
Z348330
Z348330
Z348330
8-21
