3-channel configuration mono with audio option

Principle drawing
TBDÃH‚v‡‚…
8uhryÃ
21<;
8uhryÃ
8uhryÃ!
The source connections are the same as for 'Base configuration for 3-channel mono'.
Audio connection is done with an extra delivered cable type 11. This cable connects the audio source with the built-in audio amplifier
in one of the projectors.
The speakers, mounted on the sides of the system should also be connected to the amplifier output with cable type 12.
Remark
One channel output from the ONYX split can be displayed on a monitor.
To display another channel, the user must manually plug the monitor cable into the corresponding MAGIC of that channel.
Necessary Equipement and Cables
The following cables are included to set up this configuration :
Cable type 1
Cable type 2
Cable type 3
Cable type 4
Cable type 11
Cable type 12
The following interfaces are necessary to set up this configuration :
MAGIC interface
Hint
As there is no power switch on the system, use socket strips with power breaker to connect the projectors, the audio option and
the Magic interfaces to the wall outlet.
R5976280 RC3300W 19072001
8hiyrÇ’ƒrÃ#
ÃphiyrÇ’ƒrÃ!
L F
D J
0
8hiyrÇ’ƒrÃ!
8hiyrÇ’ƒrÃ"
L F
D J
0
8hiyrÇ’ƒrÃ" 8hiyrÇ’ƒrÃ!
F
J L
0 D
8hiyrÇ’ƒrÃ" 8h iyrÇ’ƒrÃ!
6ˆqv‚Æ‚ˆ…pr
Description
RS232 communication cable 6.5ft
5 BNC to 5 BNC coax cable 15m/50ft
13W3 to 4 BNC 4.6ft
5 BNC to DD15male 6.5ft
Audio cable
Audio cable
BNC-BNC coupling pieces
3x R9828121 (230V) or R9828128 (120V) according to the ordered destination kit.
8uhryÃ
8hiyrÇ’ƒrÃ
8hiyrÇ’ƒrÃ
8hiyrÇ’ƒrÃ
Quantity Order number
2 Z348755
4 Z348333
3 Z348261
1 K344073
1
2
4 R313667
Configurations
8uhryÃ!
8uhryÃ
!
8hiyrÇ’ƒrà !
7ˆvy‡v
6ˆqv‚ƈƒƒy’
Ãh€ƒyvsvr…
8hiyrÇ’ƒrÃ
8-15
