Configurations
The following extra equipment is necessary to set up this configuration :
All these peripherals are mounted in a RACK, and delivered as one unit. The order numbers and quantities are only given as information
for after sales orders.
MAGIC interface
RCVDS05
Quad Splitter
Quad Switcher
VSE40
Hint
As there is no power switch on the system, use socket strips with power breaker to connect the projectors, audio amplifier and the
RACK to the wall outlet.
Internal Connections RACK system 2-channel sytem
See 'Internal Connections RACK system 2-channel sytem' under paragraph '2-channel configuration mono with switching option'.
Connection table internal connections RACK system
See 'Connection table internal connections RACK system' under paragraph '2-channel configuration mono with switching option'.
8-32
2x R9828121 (230V) or R9828128 (120V) according to the ordered destination kit.
2x R9828700 (230V) or R9828709 (120V) according to the ordered destination kit.
2x R9828300 (230V) or R9828309 (120V) according to the ordered destination kit.
1x R9828311 (230V) or R9828319 (120V) according to the ordered destination kit.
1x R9828520 (230V) or R9828529 (120V) according to the ordered destination kit.
