Johnson Controls WNC1800 Quick Start Manual

WNC Gateway Network Setup
7
To setup the WNC Gateway Network:
a. In the WNC Gateway UI, navigate to WNC > Net-
work Setup.
b. Set Routing to Enabled.
c. Assign a site-unique BACNet Device Object Identi-
fier.
d. Assign a site-unique Wireless Field Bus Network
address
e. Enter True for Commit Changes and Reset.
Use the WNC Gateway
8
Use the web pages from the WNC Gateway to
view, commission, and configure devices as needed.
•
Part No. 24-10737-105, Rev. A
WNC Gateway
The WNC Gateway is used in conjunction with a
ZFR1820 or ZFR1823 coordinator radio to create a wire-
less field bus using the ZFR Pro wireless protocol. It also
acts as a web server that leverages the power of mobile
connectivity to maximize productivity for daily operations.
• Commission, configure, and access building automa-
tion equipment using Wi-Fi-enabled devices such as
smartphones, tablets, and laptops.
• Change and configure setpoints, parameters, and
schedules. View alarms and trends through an
HTML5 browser-based interface.
IMPORTANT: Keep your WNC Gateway in the sta-
tionary cradle with which it shipped. This may help
protect the unit if it is dropped.
IMPORTANT: Save this guide. It contains default
Username and Password information that may be
needed to reset your WNC Gateway to factory
defaults.
