Use #10 screws with anchoring devices suitable for the wall
material where the Charging Unit will be placed.
1. Insert two mounting screws
1
inches apart. Allow about
1
2
of an inch between the
3
16
wall and screw heads for
mounting the phone.
2. Plug the AC Adapter into the
Charging Unit as previously
described. Wrap the AC
Adapter cord around the
strain relief.
3. Place the Charging Unit on
the posts of the wall screws
and push down until it's firmly
seated.
4. Plug the AC Adapter into a
standard 120V AC wall outlet.
3/16"
3/16"
1 1/2"
16
1 1/2"
Strain
Relief
Strain
Relief
AC
AC
Adapter
Adapter
