Uniden Modro 20 Owner's Manual

Hide thumbs


Quick Links

Modro 20
For more exciting new products please visit our website:



  Related Manuals for Uniden Modro 20

  Summary of Contents for Uniden Modro 20

  • Page 1 Modro 20 For more exciting new products please visit our website: Australia:
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • This unit is NOT waterproof. DO NOT expose this unit to moisture. • DO NOT expose this unit to rain.
  • Page 3 WHAT’S IN THE BOX? AC Adaptor Modro 20 Base with Cordless Handset Not Pictured: • Rechargeable Batteries Telephone Cord • Owner’s Manual • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website:...
  • Page 4: Table Of Contents

    Contents installing your phone ..........5 getting to know your phone ........6 BasiC operations ............10 menu setting..............11 Phone Book ....................... 11 Call Log ....................... 13 Base Setting .......................13 Handset Setting ....................14 Registration .......................18 speCial Features ............19 Call Transfer .......................19 important inFormation ..........20 Solving Problems ....................20 one-year limited warranty ........
  • Page 5: Installing Your Phone

    installing your phone Charge the Battery for the Handset 1. Unpack handset, battery cover and batteries. 2. Place the rechargeable AAA batteries (included) in the battery groove as shown in the figure (ensure correct polarity). 3. Place the battery cover and securely lock it into place.
  • Page 6: Getting To Know Your Phone

    getting to know your phone Handset...
  • Page 7 Keys/Icon What it does Display PHONE In standby, press to view the phonebook. BOOK INTERCOM Press to set up an internal call to another handset; or to transfer an incoming call to another handset; • In the menu list, move one line up. • During a call, press to increase the speakerphone volume.
  • Page 8 Base Keys/Icon What it does 14 Find HS Press to page all handsets 15 LED In Use/Charge LED...
  • Page 9: Handset Lcd Display

    Handset LCD Display Icon What it means Indicates the signal strength. It flashes when the registration to the base is lost. Talk mode Handset keypad is locked. Indicates alarm on. Flashes when triggered. Ringer off Phonebook Voice message waiting Indicates that the same call has been received more than once.
  • Page 10: Basic Operations

    BasiC operations Make a Call 1. In the standby mode, use the keypad to dial the desired number. If you make a mistake, press F/DEL to clear the digits one by one. To clear all digits, press 2. Press the LCD displays ‘LINE IN USE’, the number will dial out. 3.
  • Page 11: Menu Setting

    menu setting Using the Handset Menu With the phone in standby, press OK to access the Menu setting. Press to scroll through the MENU list. Press OK to select a setting. Press to quit current setting. Press to quit the setting. PHONE BOOK Each handset has its own phone book, independent of the other, with a maximum of 50 entries.
  • Page 12: Delete All

    2. Press ▲ or ▼ to scroll through the list and select the desired number. 3. Press OK and the cursor will flash at the end of the contact name. Use F/DEL to delete the letters and the key pad to enter the characters. 4. Press OK to confirm and the cursor will appear near the digits. Use F/DEL to delete the digits and the key pad to enter the digits.
  • Page 13: Call Log

    CALL LOG 1. Press OK to enter the menu settings and press ▲ or ▼ to select CALL LOG. 2. Press OK to confirm and enter the CALL LOG setting. Press ▲ or ▼ to scroll through MISSED, RECEIVED or DIALLED list. 3. Select the desired list and press OK to confirm. Press ▲ or ▼ to scroll through the list. If the list is empty, the LCD will display EMPTY. 4. Select the displayed number on the LCD by pressing OK. Press ▲ or ▼ to view the options available - ADD TO PB?, DELETE?, DELETE ALL?. 5.
  • Page 14: Modify Pin

    MODIFY PIN Some functions require a PIN code. The default PIN is 0000, but you can change it to your personal 4-digit PIN. 1. Enter the BASE SETTING menu and press ▲ or ▼ to select MODIFY PIN, press OK to confirm. 2. The LCD displays, PIN? Use the key pad to enter the default pin (0000) and press OK to confirm.
  • Page 15 • In the standby mode, the alarm will ring at the time you set. • When the alarm is triggered, press any key to turn it off. If a call comes through at that time, the alarm will automatically turn off. • To turn it off, re-enter the setting and turn it off.
  • Page 16: Auto Answer

    HS NAME This options allows you to set a display name. 1. Enter the HS SETTINGS menu and press ▲ or ▼ to scroll through the list and select HS NAME. Press OK to confirm. 2. Use the keypad to enter a name. If you want to delete a character, press F/DEL.
  • Page 17: Select Base

    SELECT BASE This handset can be registered to more than one base. 1. Enter the HS SETTINGS menu and press ▲ or ▼ to scroll through the list and select SELECT BASE. Press OK to confirm. 2. The LCD displays BASE 1 +. Press ▲ or ▼ to select base (BASE 1~4) or AUTO. Press OK to confirm. If you select AUTO, the handset will link with the first available base.
  • Page 18: Registration

    REGISTRATION The handset supplied with the base is already registered. You do not have to register it again. To check whether a handset is registered, power on the unit and ensure that the handset is within the range of the base. The handset’s display should show a number, (for example, HS 1 or HS 2) and the icon for signal strength displayed on the LCD should show three bars.
  • Page 19: Special Features

    speCial Features Call Transfer Transfer a call from one handset to another. 1. During a call, press . You will be prompted to enter the number of the internal handset with which you wish to connect. The relevant internal handset will ring. 2.
  • Page 20: Important Information

    important inFormation Solving Problems If you have any trouble with your phone, check this section first. If you need help, visit the customer support page of our website listed on the front cover. General Problems Possible Solutions • Check the line cord. Connect Telephone Blank or faint screen Cord.
  • Page 21: One-Year Limited Warranty

    (“Uniden Aust”). Terms of Warranty Uniden Aust warrants to the original retail purchaser only that the Modro 20 (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period, subject to the limitations and exclusions set out below.
  • Page 22 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
