Related Manuals for Uniden DECT 3035
Summary of Contents for Uniden DECT 3035
- Page 1 DECT 3035 For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
- Page 2 DECT 3035 Series Owner’s Manual You will also find: What's in the box? Accessory handset DECT 3035 and charger base with answering system and Not pictured: cordless Rechargeable handset battery (BT-694 or BT-694s) Battery cover AC adapter AAD- 600S(M) If you purchased...
-
Page 3: Table Of Contents
What’s in the manual? Getting Started ........4 Personalizing the Greeting ....16 Installing Your Phone ........4 Accessing the Answering System ..17 Getting to Know Your Phone ....5 Getting Your Messages ......17 Using the Handset Menu ......8 Using the System While You’re Away from Home .......... -
Page 4: Getting Started
GETTING STARTED Installing Your Phone Charge the Battery 1. Unpack all handsets, battery packs, and battery covers. If you need to remove a cover, press in on the notch and slide the cover down and off. Line up the battery connector with the jack inside the handset;... -
Page 5: Getting To Know Your Phone
Display Getting to Know Your Phone Parts of the Handset PHONEBOOK SPEAKER MENU/SELECT TALK/FLASH DOWN Twelve-key dial pad REDIAL/PAUSE Microphone INTERCOM/CLEAR MESSAGE/MUTE Charging contacts Key (icon) What it does In standby or during a call: open the phonebook. PhonEbook In the menu: go back to the previous screen. When entering text: move the cursor to the left. - Page 6 Key (icon) What it does In standby: start an intercom call. inTErcoM/ During a call: put the call on hold and start a call transfer. clEar When entering text or numbers: erase the character at the cursor (press & hold to erase all characters). In standby: access your answering system.
- Page 7 Parts of the Base FIND HS DELETE DOWN Charging ANS ON/OFF PLAY/STOP contacts What it does (icon) In standby: page all handsets. find hS anS on/ In standby: turn the answering system on or off. While playing a message: restart the message. In the first 2 seconds of a message: play the previous message.
-
Page 8: Using The Handset Menu
Using the Handset Menu Press MENU/SELECT open the menu. Press MENU/SELECT to choose Handset Setup the current option. Ans. Setup Handset Setup Press T-coil Handset Setup PHONEBOOK DOWN go back a screen Ringer Tones Handset Setup rotate through the options. press to exit Personal Ring... -
Page 9: Entering Text On Your Phone
Menu Date & Time Use this menu to set the clock (if you have Caller ID, the phone sets date and time automatically). Enter the date and time (DD/MM/YY); select or PM. Use to move the cursor past a digit without changing it. Menu Global Setup The settings on this menu affect all handsets. -
Page 10: Using Your Phone
USING YOUR PHONE This section explains the most common functions on the phone. To... Using the earpiece Using the speakerphone make a call, dial the press press Talk/flaSh SPEakEr number & answer a call press press Talk/flaSh SPEakEr hang up press or put the handset in the cradle. - Page 11 Using the Caller ID and Redial Lists You have to subscribe to Caller ID, Call Waiting, and Caller ID on Call Waiting services to use the features described in this section: contact your telephone provider for more information. Caller ID list Redial list The phone saves the information for the Each handset remembers...
-
Page 12: Using The Phonebook
Using Call Waiting Call Waiting, a service available from your telephone provider, lets you ♦ receive calls while you are on another call. Caller ID on Call Waiting (CIDCW) service displays Caller ID information for a waiting call. If you get a Call Waiting call, the phone sounds a tone and displays any CID information received from the waiting call. -
Page 13: Adding Phonebook Entries
Adding Phonebook Entries With the phone in standby, open the phonebook. Press MEnu/SElEcT select Create New. Enter a name & number and select a personal ring. Enter the phone number (up to 20 digits) exactly as you would dial it. ♦... -
Page 14: Conference Calling
If a handset was ever registered to a base, you must reset it before it ♦ can register to a new base; see p. 21, or see the accessory handset manual. Conference Calling When an outside call comes in, two handsets can join in a conference ♦... -
Page 15: Chain Dialing
To... Press... make an intercom inTErcoM/clEar. Select the handset you want to talk with, page to page all handsets at the same time. cancel a page answer a page inTErcoM/clEar Talk/flaSh end an intercom . Both handsets return to standby. call Chain Dialing If you often have to enter a series of digits or a code number during a... -
Page 16: Personalizing The Greeting
Set the number of rings (6, 9 or 12) before the system Ring Time answers. Toll Saver makes the system answer after 2 rings if you have new messages or after 4 rings if you don't. Set the amount of time (1 or 4 minutes) callers have to leave Record Time... -
Page 17: Accessing The Answering System
Accessing the Answering System When the phone’s in Press MESSAGE/MUTE to start remote operation mode. standby, you can access the system from any handset: PHONEBOOK to go to 4:Delete go back to the the next option: Only 1 handset can access ♦... -
Page 18: Using The System While You're Away From Home
Screening Your Calls You can use the answering system for call screening. While the system takes a message, you can listen on the base speaker (if you turn on Call Screen) or from a handset. Only one handset can screen calls at a time. If another handset tries to screen calls, it beeps and returns to standby. -
Page 19: Important Information
If you don't press any keys for 15 seconds, the system hangs up and return to standby. IMPORTANT INFORMATION Solving Problems If you have any trouble with your phone, check this section first. If you need help, visit the customer support page of our website listed on the front cover. - Page 20 Caller ID problems Possible solutions No handsets Let calls ring twice before answering. display Caller ID Make sure your Caller ID service is active. information. Caller ID displays You may have to change the line mode. Visit the briefly and then customer support page on the website for more information.
-
Page 21: Resetting Handsets
Installing a Line Filter or DSL Filter A telephone line filter or DSL filter prevents services that use the phone line from causing interference on your phone. To get a line filter, contact your service provider or look in an electronics store. Plug the filter into the telephone wall jack and plug the base into the filter. -
Page 22: Adapter And Battery Information
Do not charge the batteries in any charger other than the one specified in the owner's manual. Using another charger may damage the battery or cause it to explode. Uniden works to reduce lead content in our products & accessories. -
Page 23: Wall Mounting The Base
This phone can be mounted on any standard telephone wall plate using an optional wall-mount bracket. You can purchase a wall-mount bracket by the online shop at www.uniden.com for Australian models and www. uniden.co.nz for New Zealand models. Route the telephone cord through the hole of the wall-mount bracket. - Page 24 Place the mounting slots over the pins on the wall plate. Wall plate (To AC outlet) Slide the base down to lock it into place. Removing the wall-mount bracket At the bottom of the base, pinch the two "nose" of the wall-mount bracket as shown, and then slide the bracket away from...
-
Page 27: One-Year Limited Warranty
One-year Limited Warranty UNIDEN DECT 3035 This product comes with a one year limited warranty. Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. IMPORTANT Evidence of the original purchase is required for warranty service. - Page 28 © 2010 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in Vietnam UNZZ01234BZ(0)
