Your unit is now fully plurr~bed in and ready t o If the unit is a Sensatronic advance t o page
programme. If the unit is a Timetronic 18.
advance t o page
1 1 .
i
RETURN HERETO FINISHTHE INSTALLATION ONCE
THE PROGRAMMING IS COMPLETE.
NOTES TO THE INSTALLER
-
BEFORE YOU LEAVE
1.
Having programmed your unit you
will wish to ensure that the unit is
functioning properly before you leave
the site.
2.
Our Service Department will offer you
advice. If you have any queries do not
hesitate to call us.
3. Open the inlet and outlet valves and
close the bypass as indicated in the
diagram
(u.6). Check that all the
plumbing connections are secure and
that there are no leaks.
4.
Check that the time of day is correct
and that for the Timetronic models, the
day is correct and that the days of
recharge have been set.
5.
CHECK METER IS CONNECTED
CORRECTLY ON SENA'TRONIC
MODELS
a) Press the SELECT button and hold for
about 3 seconds (as per page 25).
b) Press the select button again and
hold until a
display shows
This indicates
the flow.
am
C)
Open a nearby softened water tap.
d) The display should give a reading
indicating the flow rate.
el If you don't get a reading, check the
meter sensor is not blocked and is
correctly connected to the faceplate
and meter elbow, and ensure that the
bypass valve is closed. (See pages 6
and 8.)
f) Press select until the present time
shows again.
6.
Initiate a Recharge.
For Timetronic Models hold down the
On/Off button for 3 seconds until RCHG
shows in the display.
For Sensatronic models hold down the
recharge button for 3 seconds until
RECHARGE flashes in the display.
After a few minutes a small amount of
water will be drawn into the Brine
Cabinet. This process will take
approximately 15-20 minutes.
At this stage some of the water will be
drawn from the cabinet and run to drain.
Again check for leaks.
7. Once the water has run to drain fill the
cabinet with salt. You will require a 25
Kg bag of Pellet or Tablet salt. DO
NOT use granular salt. For best
results Ecowater Systems recornmend
AQUASOL.
Make sure that the brinewell cover is in
place and secure as salt must not be
allowed to enter the brinewell. Do not fill
salt above the overflow.
8.
The whole recharge procedure will take
approximately
1
hour and softened
water will gradually replace the hard
water in the storage tank over a period
of 2-3 weeks.
9.
Advise the customer that those water
outlets fed from the header tank will not
see softened water immediately.
However, following the recharge
appliances drawing directly from the
water softener may be tested for
softened water.
10. Unless otherwise specified, warranty on
the unit will be undertaken by Ecowater's
Service Department.
However, call outs not due to the water
softener but to installation problems or
incorrect usage will be chargeable.
11. Ensure that the customer is left with all
literat~~re relating to the unit and that the
guarantee card is retl~rned immediately
to effect the full warranty.
