Animo OptiBean Service Book page 25

OptiBean (XL)
Service menu continued ...
Main item Sub-item Sub
2.7 Hardware test Inputs Temp
Drip tray sensor
Waste bin
Door switch 1 (pin)
key switch
brewer switch 1 (right)
brewer switch 2 (left)
Door switch 2 (lock)
Key panel
Service panel
Outputs KW1
DV1
Test by holding
in recipe button
DV2
11.
DV4
# During test the
DV5
display shows
the Nominal
DV6
current (mA).
IM1 #
When the
Nominal IM3 #
current of a out-
IM4 #
put rises above
the set current *
BM #
mentioned output
will be shut off.
MM2 #
Ventilator
LED's
KW2
KW3
OptiLight
Calibration water Flow meter
system
KW1
Pump
Range Description
Boiler temp °C Shows the status of the sensors/switches
concerned
yes/no
yes/no
yes/no
13 14 15 16
yes/no
1
7
2 8
yes/no
5
3 9
4
10
yes/no
4
5
11
6 12
yes/no
17 18
Inlet valve (Boiler)
DoseerVentiel (measuring valve) 1 (Brewer)
DoserVentiel (measuring valve) 2 (Mixer 2)
500mA
DoseerVentiel (measuring valve) 4 (Hot water)
Measuring valve 5 (n.a.)
NO valve
Grinder motor 1
600mA Ingredient motor 3
Ingredient motor 4
900mA Brewer motor
1000mA Mixer motor 2
200mA Fan
LED's
Pump (via SSR)
500mA
Measuring valve KW3 cold water
Red, Green, Blue
1.850 p/ml With this (if necessary) the À ow meter can be
(1.700-2.000) calibrated.
The calibration is not described because it is not
expected that it will ever have to be carried out.
Check/set the pump pressure (10 bar).
Connect the manometer to the boiler inlet.
Caution! Release the pressure in the boiler ¿ rst
using 2.14 Installation / Shut down.
Press the test key, activate KW1 (inlet valve),
KW2 (pump) and DV6 (NO valve).
Adjust the pump pressure (see Section 5.4) with
the adjustment screw on the pump housing.
Stop measurement; press any key.
48 2013/08 Rev. 0.5
OptiBean (XL)
Service menu continued ...
Main item
2.7 Hardware test
(continued...)
3
1
2
2013/08 Rev. 0.5
Sub-item Sub Item
Brewer/Mixer(s)
Brewer
Operating hours
Mixer 2
Ingredient
IM 1 (grinder)
motor(s)
IM 3 (topping)
IM 4 (cocoa)
Pump KW2 (pump)
Valves DV1 (brewer)
DV2 (mixer)
DV4 (hot water)
DV5
DV6 (NO valve)
KW1 (inlet valve)
KW3 (cold water)
Element Element 1
Element 2
49
Description
Day - Hour : Min.
0 - 00 : 00
Number x activated
GB
_ _ _ _ x
