OptiBean (XL)
Key switch
Software menu parameter
Key Multicup Free
switch vend
Yes
0
No
0
Yes
>1
No
Yes
0
No
1
Yes
>1
No
Yes
0
No
2
Yes
>1
No
Yes
0
No
3
Yes
>1
No
Yes
0
No
4
Yes
">1
(2)"
No
Table 2
Key switch
Payment system
G13 / MDB
(off) (on)
n.a. free cup free cup
Yes paid cup free cup
No free cup free cup
n.a. free jug free jug
Yes paid jug free jug
No free jug free jug
n.a. free cup free cup
Yes paid cup free cup
No free cup free cup
n.a. free cup free jug
Yes paid cup paid jug
No free cup free jug
n.a. not possible free cup
Yes not possible free cup
No not possible free cup
n.a. not possible free jug
Yes not possible paid jug
No not possible free jug
n.a. free cup free cup
Yes paid cup free cup
No free cup free cup
n.a. free cup free jug
Yes paid cup free jug
No free cup free jug
n.a. free cup free cup
Yes paid cup free cup
No free cup free cup
n.a. free jug free jug
Yes paid jug free jug
No free jug free jug
42 2013/08 Rev. 0.5
OptiBean (XL)
Service menu continued ...
Main item Sub-item Sub Item
2.3 Recipe settings <Recipe name> 1 Unit 1 DV 1 WT
DV 1
Coffee WT
Coffee
Brewer WT1
PI time
PI pause
<Recipe name> 12
Brewer WT2
Pressure WT1
Pressure time
Pressure WT2
Unit 2 DV 2 WT
DV 2
Rinse 2 WT
Rinse 2
Topping WT
Topping
Cacao WT
Cacao
Mixer 2 WT
Mixer 2
2013/08 Rev. 0.5
Range Set Description
0.0-30.0 s Waiting time Water 1
Pressure valve measurement
0-100 ml
quantity)
0.0-30.0 s 0.5 s Coffee grinder delay time
Coffee grinder coffee dispensing
0.00-5.00 s
time
Brewer delay time 1 after grinding
0.0-30.0 s 0.5 s
coffee.
Pre-infusion time (PI time).
The brewer valve is open for the
set PI time, the coffee powder is
0.0-15.0 s 2.0 s.
moistened at water supply pressure
(approx. 2 bar).
Note: if coffee is still coming out
of the brewer, the PI time is too long.
Pre-infusion pause (PI pause).
The brewer valve is kept closed
during the set PI pause; the coffee
0.0-15.0 s 0.5 s.
swells up.
Note: the Pre-infusion function can
simply be turned ON/OFF in menu
2.2 Button settings) / Pre-infusion).
Brewer delay time 2 after making
0.0-15.0 s 3.0 s. coffee. This affects the residual
moisture in the coffee pellet.
Delay time between unit 2 and unit
1 Mainly used for extending the time
0.0-15.0 s
between topping and coffee for Latte
macchiato.
The pressure boiler is brought to low
0.0-15.0 s
pressure.
Delay time 2 after the pressure
0.0-15.0 s boiler is reduced to low pressure
again.
0.0-30.0 s Pressure valve delay time 2
pressure valve measurement
0-100 ml
quantity 2
Pressure valve rinse water delay
0.0-20.0 s
time 2
Pressure valve rinse water quantity).
0-15 ml
Is automatically offset by DV 2
0.0-30.0 s Topping delay time
0.00-5.00 s Topping product dispensing time
0.0-30.0 s Cocoa delay time
0.00-5.00 s Cocoa product dispensing time
0.0-30.0 s Delay time Mixer 2
0.0-50.0 s Running time for Mixer 2
