OptiBean (XL)

How check the weight?

Only the grinder / ingredient motor will be driven (no
water is dispensed).
It is strongly recommended to check the coffee
measurement using a set of mini scales. These
are simple to order via the Internet.
2.1 Quick recipe pro
2.1.01 Coffee (drink)
Coffee
Coffee beans(ingredient)
2.1.04 Cappuccino (drink)
Cappuccino
Coffee beans(ingredient)
Cappuccino
Topping (ingredient)
1. Navigate to above service menu item
2. Hold a empty cup under the outlet.
3. Press the TEST button, only the chosen ingredient
will be dispensed.
4. Measure the weight of the ingredient*
*Coffee
Standard espresso group: min. 6,5 - max. 9,0 g.
XL espresso group: min. 9,5 - max. 12,5 g.
Rules for the adjustment
• There are two factors that affect the output of the
coffee grinder. The grinder rotation time
(2.1 Quick recipe pro / Coffee) and the grinding
¿ neness of the coffee grinder.
• When the coffee grinder is set coarser, the volume of
the grind increases.
• When the coffee grinder is set finer, the volume of
the grind decreases.
• Only adjust the grinder finer when the grinder is
running! Adjustment from fine to coarse can be done
when the grinder is stationary.
• Only adjust the grind setting in steps of 1/4 turn.
Note: only the 3rd cup of coffee is 100% made
with the changed grind fineness! (do not measure
the first 2 cups).
• The coffee brewing process time is from the moment
when the pump starts until the moment the pump stops.
? gram
TEST
START
3
2
30 2013/08 Rev. 0.5
OptiBean (XL)

How to check a drink?

Easy way to check the dispensed drink- volume and
taste without leaving the menu!
2.1 Quick recipe pro
2.1.01 Coffee (drink)
2.1.04 Cappuccino (drink)
1. Navigate to above service menu item
2. Change one or more settings and confirm (v),
(START led blinks).
3. Place a empty cup under the outlet and press the
START button. You drink is made.
When the Cup volume (menu parameter) is
increased, instant products Topping and
Chocolate will be automatically proportional
increased. The coffee however will not
automatically increased!
Only adjust the grind setting in steps of 1/4 turn.
Note: only the 3rd cup of coffee is 100% made
with the changed grind fineness! (do not
examine the first 2 cups).
Try to find a balance between:
• Cup volume
• Amount ground coffee
• Ground coffee coarse or fine (grinder adjustment)
If the optimum settings are found for the first coffee
button copy the set grinder time for all the coffee drinks;
Coffee Milk, Espresso, Cappuccino, Latte Macchiato,
1
etc.
2013/08 Rev. 0.5
Coffee
Coffee beans (ingredient)
Cappuccino
Cup volume
Cup volume 120ml
Cappuccino
Coffee (ingredient)
Coffee 1,45s.
Cappuccino
Topping (ingredient)
Topping 2,50s.
(menu setting)
(menu setting)
31
120-150ml
Standard
GB
20-30 sec.
150-230ml
XL
30-40 sec.
*
START
3
2
1
