New Threshold Alerts Dialog Box-First Screen; New Threshold Alerts Dialog Box-Second Screen - HP StorageWorks Edge Switch 2/32 Installation Manual

2. Click New. The New Threshold Alert dialog box is displayed, as shown in
Figure 32 New Threshold Alerts dialog box
3. Enter a name from one to 64 characters in length in the Threshold Alert Name field. All
characters in the ISO Latin-1 character set, excluding control characters, are allowed.
4. Select one of the following from the Threshold Type drop-down list:
• Transmit—An alert will occur if the threshold set for transmit throughput is reached.
• Receive—An alert will occur if the threshold set for receive throughput is reached
• Receive and Transmit—An alert will occur if the threshold set for either receive or transmit
throughput is reached.
5. Click Next. A new screen is displayed with additional parameters, as shown in
name configured for the alert appears at the top of the screen.
NOTE: Click Previous if you need to return to the previous screen.
Figure 33 New Threshold Alerts dialog box
first screen
—
second screen
—
Edge Switch 2/32 installation guide
Figure 32.
Figure 33. The
59
