Page 1 HP StorageWorks Edge Switch 2/32 installation guide FW 07.00.00/HAFM SW 08.06.00 Part number: AA–RSTZE–TE/958–000290–003 Fifth edition: March 2005...
Page 2 Hewlett-Packard. The information is provided “as is” without warranty of any kind and is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
Page 3: Table Of Contents
HP-authorized reseller ........
Page 4 Install the Edge Switch in a Rack ..........26 Rack mount checklist .
Page 5 Configure, enable, and test call home event notification ......57 Configure threshold alerts ..........57 Create new alerts .
Page 6 A Regulatory compliance and safety ........95 Regulatory compliance .
Page 7 Attaching the slide rail to the switch ......... . 29 Connection Description dialog box .
Page 8 54 Domain Information dialog box ..........85 55 Firmware Library dialog box .
Page 9: About This Guide
Related documentation or a list of corresponding documentation included with this product, see the Related documents section of the HP StorageWorks Edge Switch release notes For the latest information, documentation, and firmware releases, please visit the HP StorageWorks website: http://h18006.www1.hp.com/storage/saninfrastructure.html For information about Fibre Channel standards, visit the Fibre Channel Industry Association website: http://www.fibrechannel.org...
Page 10: Document Conventions And Symbols
Convention Element Medium blue text: Figure 1 Cross-reference links and e-mail addresses Medium blue, underlined text Web site addresses (http://www.hp.com) Bold font • Key names • Text typed into a GUI element, such as into a box • GUI elements that are clicked or selected, such as menu and...
Page 11: Rack Stability
• Detailed, specific questions For continuous quality improvement, calls may be recorded or monitored. HP strongly recommends that customers sign up online using the Subscriber's choice web site at http://www.hp.com/go/e-updates. • Subscribing to this service provides you with e-mail updates on the latest product enhancements, newest versions of drivers, and firmware documentation updates as well as instant access to numerous other product resources.
Page 12: Helpful Web Sites
Helpful web sites For third-party product information, see the following HP web sites: • http://www.hp.com • http://www.hp.com/go/storage • http://www.hp.com/support/ • http://www.docs.hp.com...
Page 13: Introduction
22 Switch description The HP StorageWorks Edge Switch 2/32 provides dynamic switched connections between Fibre Channel servers and devices in a storage area network (SAN) environment. SANs introduce the concept of server-to-device networking and multiswitch fabrics, eliminate requirements for dedicated connections, and enable the enterprise to become data centric.
Page 14: Switch Management
CLI is to automate management of a large number of switches using scripts. The CLI is not an interactive interface; no checking is done for pre-existing conditions and no prompts display to guide users through tasks. Refer to the HP StorageWorks CLI reference guide for directors and edge switches.
Page 15 The trap messages indicate operational state changes and failure conditions. NOTE: For more information about SNMP support provided by HP products, refer to the HP StorageWorks SNMP reference guide for directors and edge switches. Edge Switch 2/32 installation guide...
Page 16: Zoning
Zoning The switch supports a name server zoning feature that partitions attached devices into restricted-access groups called zones. Devices in the same zone can recognize and communicate with each other through switched port-to-port connections. Devices in separate zones cannot communicate with each other. Zoning is configured by authorizing or restricting access to name server information associated with device N_Ports that attach to switch fabric ports (F_Ports).
Page 17: Front View
Front view Figure 1 shows the front of the Edge Switch 2/32 and identifies the front panel components. StorageWorks edge switch 2/32 Initial machine load (IML) button Port LEDs Ethernet LAN connector Error LED (amber) SFP fiber-optic connectors Power LED (green)
Page 18: Sfp Transceivers (Fiber Optic Connectors)
SFP transceivers (fiber optic connectors) A single-mode or multimode fiber-optic cable attaches to a port through a small form pluggable (SFP) transceiver. The SFP provides a duplex LC interface, and can be detached from the switch port for easy replacement. Two fiber-optic transceiver types are available: •...
Page 19: Ethernet Lan Connector
• Ports, causing all Fibre Channel connections to drop momentarily until the connections automatically recover. An IML should only be performed if a CTP failure is indicated. Do not IML the switch unless directed to do so by a procedural step in this manual or by the next level of support. As a precaution, the IML button is flush mounted to protect against accidental activation.
Page 20: Tools And Test Equipment
Tools and test equipment This section describes tools and test equipment that may be required to install, test, service, and verify operation of the switch and attached on the HAFM appliance. Tools supplied with the switch The following tools are supplied with the switch. Use of the tools may be required to perform one or more installation, test, service, or verification tasks.
Page 21: Tools Supplied By Service Personnel
• Null modem cable—An asynchronous RS-232 null modem cable as shown in Figure 5 required to configure switch network addresses and acquire event log information through the maintenance port. The cable has nine conductors and DB-9 male and female connectors. Figure 5 Null modem cable Tools supplied by service personnel...
Page 22: Optional Kits
Optional kits Contact your HP authorized service provider to purchase the following optional Edge Switch 2/32 kits. See Table Table 2 Edge Switch 2/32 optional kits Supporting Kit Description 8-flexport upgrade for the Used to upgrade from 16 to 24 and from 24 Edge Switch 2/32 to 32 ports.
Page 23: Installing And Configuring The Edge Switch 2/32
A site plan is prepared, configuration planning tasks are complete, planning considerations are evaluated, and related planning checklists are complete. Fabric and device connectivity are evaluated, and the related planning worksheet is complete. Refer to the HP StorageWorks HA-Fabric Manager User Guide.
Page 24: Unpack And Inspect The Switch
Verify that the following items are present before beginning installation: • (Optional). An HP 9000, HP 10000, HP 11000, HP M-Series, HP rack system/e, or an industry-standard 19-in rack. • Two power outlets or different branches (for redundancy) • Torque driver with cross-tip bit (for setting 22 in/lb. of torque) •...
Page 25: Install The Edge Switch On A Desktop
After successful POST completion, the green power (PWR) LED remains on and all other front panel LEDs turn off. If a POST error or other malfunction occurs, refer to the HP StorageWorks Edge Switch 2/32 service manual to isolate the problem.
Page 26: Install The Edge Switch In A Rack
Install the Edge Switch in a Rack This section describes how to rack mount the HP StorageWorks Edge Switch 2/32 in the appropriate HP, or comparable, 19-inch Electronic Industries Association (EIA) rack: HP 9000 series, 10000 series and 11000 series racks •...
Page 27: Required Tools
10x32 panhead screws to complete this procedure. NOTE: If you are installing the Edge Switch 2/32 in an HP 9000, 10000 or 11000 series rack, you will need eight square alignment washers to complete this procedure. Determine the position of the switch in the rack. Each Edge Switch 2/32 is 1.75 inches or 1U high.
Page 28: Mounting The Slide Rails On The Sides Of The Switch
Do not install a screw in the center hole of each bar nut. NOTE: a. If you are installing the Edge Switch 2/32 in an HP 9000, 10000 or 11000 series rack, place a square alignment washer on each panhead screw before inserting in the square cabinet frame holes.
Page 29: Installing The Switch In The Cabinet
Using the torque driver and the screws you removed earlier, attach the left and right slide rails to the Edge Switch 2/32. Figure 7 Attaching the slide rail to the switch Installing the switch in the cabinet Use these steps to install the switch in the cabinet. You will need a #2 Phillips screwdriver and two rear spacing brackets to complete this procedure.
Page 30: Configure Switch Network Information
NOTE: If you have enabled additional port function with the HP Flexport feature since the switch shipped from the factory, resetting the configuration will return this feature to the factory default of only 16 ports enabled. You must re-enable the additional ports using the Configure Feature Key dialog box (see ”Configure feature...
Page 31: Changing The Switch Address
Changing the switch address If multiple switches are installed or a public LAN segment is used, network addresses must be changed to conform to the customer’s LAN addressing scheme. The following items are required to perform this task: • A local workstation (desktop or notebook computer) with: •...
Page 32: Connect To Dialog Box
Enter edge switch 2-32 in the Name field and click OK. The Connect To dialog box is displayed (Figure Figure 9 Connect To dialog box Ensure that the Connect using field displays COM1 or COM2 (depending on the serial communication port connection to the switch), and click OK. The Port Settings dialog box is displayed (Figure 10).
Page 33: Hyperterminal Window
At the > prompt, enter the user-level password (the default is password) and press Enter. The password is case sensitive. The HyperTerminal window is displayed with a C> prompt at the top of the window (Figure 11). Figure 11 HyperTerminal window At the C>...
Page 34: Lan-Connect The Switch
If the switch is installed on a customer-supplied LAN segment, connect the cable to the LAN as directed by the customer’s network administrator. b. If the switch is installed on the HP-supplied Ethernet hub, connect the cable to any available port on the hub.
Page 35: Record Or Verify Hafm Appliance Restore Information
Configuration information must be recorded to restore the HAFM appliance in case of hard drive failure. The Windows operating system and the HAFM and Element Manager application must also be restored. Refer to the HP StorageWorks HA-Fabric Manager appliance installation guide for instructions.
Page 36: Verify Communication Between The Switch And The Hafm Appliance
Enter the switch IP address (determined by the customer’s network administrator) in the IP Address field. Enter the switch subnet mask (determined by the customer’s network administrator) in the Subnet Mask field. At the Data Source for Domain area of the dialog box, select the Use auto detection, Use the server, or Use a specific RDC radio button (determined by the customer’s network administrator).
Page 37: Switch Hardware View Page
If the switch displays the Degraded state or a switch failure is indicated (FRU alert symbols and a yellow triangle or red diamond at the alert panel), refer to the HP StorageWorks Edge Switch 2/32 service manual to isolate the problem.
Page 38: Set Switch Date And Time
Set Switch date and time The Edge Switch 2/32 Element Manager log entries are stamped with the date and time received from the switch. To set the effective date and time for the switch: At the Hardware View page for the selected switch, select Configure > Date/Time. The Configure Date and Time dialog box is displayed (Figure 17).
Page 39: Frequently Used Hafm Settings
Activate to enable synchronization and close the Configure Date and Time dialog box. Frequently used HAFM settings This section summarizes the most common HAFM tasks, including: NOTE: For a complete reference on HAFM functionality, refer to the HP StorageWorks HA-Fabric Manager user guide. • Set the switch online, page 39 •...
Page 40: Set The Switch Offline
If the switch is installed on a public LAN, the name should reflect the switch’s Ethernet network DNS host name. For example, if the DNS host name is hpes232.hp.com, enter hpes232. b. Click Set Name as Nickname and add a check mark if you want to use the name in the name field as the nickname for the switch’s WWN.
Page 41: Configure Switch Management Style
c. Type a switch description of 255 or fewer alphanumeric characters in the Description field. d. Type the switch’s physical location (255 or fewer alphanumeric characters) in the Location field. e. Type the name of a contact person (255 or fewer alphanumeric characters) in the Contact field.
Page 42: Configure Switch Operating Parameters
Configure Switch Operating Parameters Use the procedures in this section to set parameters on the switch for fabric operation through the Configure Switch Parameters dialog box. These operating parameters are stored in NVRAM on the switch. The switch must be offline to change the Preferred Domain ID and other operating parameters. Ensure that the switch is set offline.
Page 43: Preferred
ID, the E_Ports segment, causing the fabric to segment. For more information on domain ID, refer to the section on domain ID assignment for multiswitch fabrics in the HP StorageWorks HA-Fabric Manager User Guide for details. Insistent This option is not supported unless the SANtegrity feature is installed.
Page 44: Domain Rscns
If rerouting delay is enabled, traffic ceases in the fabric for the time specified in the E_D_TOV field of the Configure Fabric Parameters dialog box. This delay allows frames sent on the old path to exit to their destination before new frames begin traversing the new path. NOTE: This option is required if High Availability Fabric Manager (HAFM) is enabled.
Page 45: Fabric Parameters
At the Hardware View, select Operating Parameters > Fabric Parameters from the Element Manager window. The Configure Fabric Parameters dialog box is displayed (Figure 20). Figure 20 Configure Fabric Parameters dialog box NOTE: Ordinarily, you do not need to change values in this dialog box from their defaults. The only exception is the Preferred Domain ID.
Page 46: E_D_Tov
Never Principal and the switch that was principal goes offline, then all of the other ISLs will segment. NOTE: HP recommends that you leave the switch priority setting as Default. If you are considering setting this value to something other than default, refer to the section on principal switch selection for multiswitch fabrics in the HP StorageWorks HA-Fabric Manager user guide for details.
Page 47: Interop Mode
Homogeneous Fabric—Select this mode if the fabric contains only HP directors and switches that are operating in Homogeneous Fabric mode. • Open Fabric 1.0—Default. Select this mode if the fabric contains HP directors and switches, as well as other open-fabric compliant switches. Select this mode for managing heterogeneous fabrics.
Page 48: Configure Ports Dialog Box (Open Systems Management Style)
Figure 21 Configure Ports dialog box (Open Systems management style) c. Click 10-100 km or RX BB Credit, depending on which column you have displayed in your Configure Ports dialog box. If a Switch supports BB credits by port, the 10-100 Km column is replaced by an RX NOTE: BB Credit column.
Page 49 Right-clicking in the RX-BB Credit column displays a RX BB Credits dialog box. For switches without buffer pools, this dialog box allows you to select Set all, which sets all ports to a single value or Set all to maximum, which set all ports to a maximum BB credit value. For switches with buffer pools, this dialog box allows you to select Set all, which sets all ports to a single value or to Distribute, which evenly distributes the pool buffers among all ports.
Page 50: Configure Preferred Ports
Configure preferred ports The preferred path feature lets you specify and configure one or more ISL data paths between multiple directors or switches in a fabric. Each participating director or switch must be configured as part of a desired path. The following rules apply when configuring a preferred path: •...
Page 51: Configure Ports (Ficon Management Style)
At the Source Port field, enter a value between 0 through 23. For this switch, the value uniquely identifies the starting port for the preferred path. At the Exit Port field, enter a value between 0 through 23. For this switch, the value uniquely identifies the exit port for the preferred path.
Page 52: Configure Port Addresses (Ficon)
If the switch is set to FICON management style, configure port addresses to access the switch matrix and define Fibre Channel port names, configure ports as blocked or unblocked, and define the CUP name. For instructions on configuring port addresses, refer to the HP StorageWorks Edge Switch Element Manager user guide.
Page 53: Configure Snmp Trap Message Recipients
Enter the IP address or DNS host name of the trap recipient (SNMP management workstation) in the associated Trap Recipient field. Use 32 or fewer alphanumeric characters. HP recommends using the IP address. d. The default user datagram protocol (UDP) port number for trap recipients is 162. Enter a decimal port number in the associated UDP Port Number field to override the default.
Page 54: Configure, Enable, And Test E-Mail Notification
Enter the IP address or DNS host name of the SMTP server in the E-mail Server field. Use 64 or fewer alphanumeric characters. HP recommends using the IP address. Enter the e-mail address to which e-mail replies should be sent in the Reply Address field.
Page 55: Hafm 8.6 Server Users Dialog Box
To specify users that are to receive e-mail notification, click User List. The HAFM 8.6 Server Users dialog box is displayed, as shown in Figure Figure 27 HAFM 8.6 Server Users dialog box To enable e-mail notification for a user, select the check box in the Email column. An unchecked box indicates e-mail notification is not enabled.
Page 56: Configure And Enable Call-Home Features
There are two call-home features available, and only one is installed when the HAFM application is installed on the HAFM appliance. To learn more about configuring call-home features, refer to the HP StorageWorks HA-Fabric Manager Appliance installation guide. Configure and enable ethernet events Perform this procedure to configure and enable Ethernet events.
Page 57: Configure, Enable, And Test Call Home Event Notification
Configure, enable, and test call home event notification Telephone numbers and other information for the call-home feature are configured through the Windows 2000 dial-up networking application. Refer to ”Configure and enable call-home features” on page 56 for configuration information. To configure, enable, and test call- home event notification: Minimize the Hardware View and return to the HAFM application.
Page 58: Create New Alerts
Use the Threshold Alerts option on the Configure menu to configure the following: • Name for the alert. • Enter of threshold for the alert (Rx, Tx, or either). • Active or inactive state of the alert. • Threshold criteria: •...
Page 59: New Threshold Alerts Dialog Box-First Screen
Click New. The New Threshold Alert dialog box is displayed, as shown in Figure Figure 32 New Threshold Alerts dialog box first screen — Enter a name from one to 64 characters in length in the Threshold Alert Name field. All characters in the ISO Latin-1 character set, excluding control characters, are allowed.
Page 60 Enter a percentage from 1 through 100 for % utilization. When throughput reaches this percentage of port capacity, a threshold alert will occur. Enter the amount of cumulative minutes in which the % utilization should exist during the notification interval before an alert is generated. You can also select At any time if you want an alert to occur whenever the set % utilization is reached.
Page 61 11.Click Next. A final screen is displayed to provide a summary of your alert configuration, as shown in Figure Figure 35 New Threshold Alerts dialog box summary screen — 12.Click Finish. The Configure Threshold Alerts dialog box is displayed with a list of the name, type, and state of the alert that you just configured.
Page 62: Modify Alerts
Modify alerts Use the following steps to modify an existing threshold alert configuration: At the Hardware View page, select Configure > Threshold Alerts. The Configure Threshold Alerts dialog box is displayed. Select the alert that you want to modify by clicking the alert information in the table. If the alert is active, an error message is displayed prompting you to deactivate the alert.
Page 63: Configure Santegrity Authentication
Configure SANtegrity authentication Use this optional feature to configure authentication security settings. You configure these setting using the SANtegrity Authentication dialog box. NOTE: You must have Administrator privileges to access the SANtegrity Authentication dialog box. To access the SANtegrity Authentication dialog box: From the Element Manager window, select Configure >...
Page 64: Back Up Hafm Configuration Data
It is important to back up the HAFM configuration data. This data is used to restore the HAFM appliance operating environment in case of hard drive failure. Refer to the HP StorageWorks HA-Fabric Manager appliance installation guide for instructions on backing up the HAFM configuration data.
Page 65: Connect Cables To Fibre Channel Ports
To provide Fibre Channel connectivity between public devices and fabric-attached devices, connect the switch to an expansion port (E_Port) of an HP director or switch. The switch port to switch port connection is called an interswitch link (ISL). To fabric-attach the switch and create an ISL:...
Page 66: Port Properties Dialog Box
Ensure that the Operational State field displays Online and the Reason field displays N/A or is blank. If an ISL segmentation or other problem is indicated, refer to the HP StorageWorks Edge Switch 2/32 service manual to isolate the problem. If no problems are indicated, installation tasks are complete.
Page 67: Unpack, Inspect, And Install The Ethernet Hub (Optional)
10/100 Mbps LAN segment. One hub port is required to connect the HAFM appliance, and one hub port is required to connect each switch. A combination of up to 48 HP switches can be configured and managed by a single HAFM appliance, therefore multiple hubs may be required to provide sufficient port connections.
Page 68: Install Hafm Client On A Remote Workstation
• Ethernet network adapter. • Java-enabled Internet browser, such as Microsoft Internet Explorer (Version 4.0 or later) or Netscape Navigator (Version 4.0 or later). Install HAFM client on a remote workstation Use these steps to install HAFM on a remote client: Verify that the workstation and the Ethernet LAN segment (with the Edge Switch 2/32 attached) are connected through the Internet.
Page 69: Launch Hafm From The Remote Client
Launch HAFM from the remote client Use these steps to launch HAFM from a remote client: Double-click the HAFM icon to launch HAFM. The HAFM Login screen is displayed. Enter the user name and password. NOTE: The default user name is Administrator. The default password is password. Both user name and password are case-sensitive.
Page 70 Installing and configuring the Edge Switch 2/32...
Page 71: Using The Embedded Web Server
HP StorageWorks Embedded Web Server user guide Launch EWS Use the following steps to launch EWS. Internet access and a standard Web browser is required. HP recommends Netscape NOTE: Navigator 4.6 or higher, or Microsoft Internet Explorer 4.0 or higher.
Page 72: Embedded Web Server Interface-View Window
At the browser, enter the IP address of the switch as the internet uniform resource locator (URL). Use the default IP address of 10.1.1.10, the factory preset of 10.1.1.10, or the IP address configured while performing ”Configure network information” on page 79. The Enter Network Password dialog box is displayed (Figure 40).
Page 73: Configure Switch Ports
(FAN) feature (default is enabled). A check mark in the box indicates FAN is enabled. When the feature is enabled, the port transmits a FAN frame after loop initialization to verify that FC-AL devices are still logged in. HP recommends enabling this option for ports configured for loop operation.
Page 74: Configure Switch Identification
If the switch is installed on a public LAN, the name should reflect the switch’s Ethernet network DNS host name. For example, if the DNS host name is hpes232.hp.com, then enter hpes232. Using the Embedded Web Server...
Page 75: Configure Date And Time
b. Enter a switch description of 255 or fewer alphanumeric characters in the Description field. c. Enter the switch physical location (255 or fewer alphanumeric characters) in the Location field. d. Enter the name of a contact person (255 or fewer alphanumeric characters) in the Contact field.
Page 76: Configure Switch And Fabric Parameters
Configure switch and fabric parameters Perform this procedure to configure the following switch and fabric operating parameters: Buffer-to-Buffer Credit (BB_Credit), Error Detect Time Out Value (E_D_TOV), and Resource Allocation Time Out Value (R_A_TOV), preferred domain ID and switch priority. Configure switch parameters The switch must be set offline to configure switch operating parameters.
Page 77: Set Fabric Parameters
b. Select Enabled or Disabled from the Insistent Domain drop-down list. The default state is disabled. This option is not supported unless the SANtegrity feature is installed. If insistent domain is enabled, the domain ID configured in the Preferred Domain ID field will become the active domain identification when the fabric initializes.
Page 78: Switch Page—Fabric Parameters Tab
• McData Fabric 1.0. (default). Select this mode if the fabric contains only M-Series switches and switches that are operating in McData Fabric 1.0 mode. • Open Fabric 1.0. Select this mode if the fabric contains HP directors and switches, as well as other open-fabric compliant switches. Select this mode for managing heterogeneous fabrics.
Page 79: Configure Network Information
Set the switch online: a. At the View window, select Operations at the left side of the panel. The Operations panel opens with the Switch Beacon page displayed. b. At the Operations panel, click the Online State tab, then click Set Online. The message Your operations changes have been successfully activated is displayed.
Page 80: Configure Snmp Trap Message Recipients
Click Activate to save the information. The following message box is displayed (Figure 48). Figure 48 Network configuration changes activated Update the address resolution protocol (ARP) table for the browser PC. a. Select File > Exit to close the Embedded Web Server and browser applications. The Windows desktop is displayed.
Page 81: Management Page-Snmp Tab
Enter the IP address or DNS host name of the trap recipient (SNMP management workstation) in the associated Trap Recipient field. Use 64 or fewer alphanumeric characters. HP recommends using the IP address. d. The default user datagram protocol (UDP) port number for trap recipients is 162. To override this port number;...
Page 82: Enable Or Disable The Cli
Enable or disable the CLI Perform this procedure to toggle (enable or disable) the state of the switch’s command line interface. To change the CLI state: At the Configure window, click the CLI tab. The Management page is displayed with the CLI tab selected, as shown in Figure Figure 50...
Page 83: Reset Configuration Data
To configure passwords: Select Configure > Security to display the Authorize Users (Auth Users) tab (Figure 51). Figure 51 Auth Users tab Under Current User Records, enter the new password in the New Password column. Use 16 or fewer alphanumeric characters. Enter the new password in the Confirm New Password column.
Page 84: Reset Configuration Dialog Box
Select the Reset Configuration option from the Maintenance menu. The Reset Configuration dialog box is displayed (Figure 52). Figure 52 Reset Configuration dialog box Click Reset to initiate the reset operation and close the dialog box. The switch IP address resets to the default address of 10.1.1.10. •...
Page 85: Domain Information Dialog Box
c. At the HAFM application, select Discover > Setup. The Discover Setup page is displayed (Figure 53). Figure 53 Discover Setup page d. Select (highlight) the entry representing the reset switch in the Available Addresses window and click Change. The Domain Information dialog box is displayed (Figure 54).
Page 86 10.Change the switch IP address and restart the management appliance session as follows: a. A grey square with a yellow exclamation mark appears adjacent to the icon representing the reset switch, indicating switch is not communicating with the management appliance. b.
Page 87: Manage Firmware Versions
Manage firmware versions The Edge Switch 2/32 internal operating code is downloaded from the HAFM appliance and stored on a CTP2 card. Up to eight versions can be stored on HAFM appliance hard drive and made available for download to an edge switch. This chapter contains information on the following firmware management tasks: •...
Page 88: Add A Firmware Version
Obtain the new firmware version from the web site web site: NOTE: The following path is subject to change. a. At the HAFM appliance or other personal computer (PC) with Internet access, open the HP web site. The uniform resource locator (URL) is http://www.hp.com/country/us/eng/storage.html.
Page 89: Firmware Library Dialog Box
Figure 58 New Firmware Description dialog box Enter a description (up to 24 characters in length) for the new firmware version and click OK. HP recommends the description include the installation date and text that uniquely identifies the firmware version.
Page 90: Modify A Firmware Version Description
Modify Firmware Description dialog box Enter a modified description (up to 24 characters in length) for the firmware version and click OK. HP recommends the description include the installation date and text that uniquely identifies the firmware version. The new description for the firmware version is displayed in the Switch Firmware Library dialog box.
Page 91: Download A Firmware Version To A Switch
Download a firmware version to a switch This procedure downloads a selected firmware version from the HAFM appliance library to an edge switch managed by the open instance of the Element Manager application. The procedure applies to an Edge switch with one CTP2 card, or a director with two (redundant) CTP2 cards. The process occurs concurrently without taking the edge switch offline or disrupting operation.
Page 92: Back Up The Configuration
• The firmware version is being installed to the edge switch by another user. • The edge switch-to-HAFM appliance fails or times out. If a problem occurs and a corresponding message is displayed, refer to the HP StorageWorks Edge Switch 2/32 service manual for specific information on isolating the problem. If no error occurs, the Send Firmware confirmation box is displayed.
Page 93: Restore The Configuration
Click Backup. An Information dialog box is displayed, indicating the backup operation was initiated (Figure 60). Figure 60 Information dialog box Click OK to complete the backup operation and close the dialog box. Restore the Configuration To restore the switch configuration file from the management appliance: Notify the customer the switch is to be set offline.
