7. GETTING TO KNOW YOUR SPA POOL
SPA POOL PARTS LABELED - CONTINUED
76
15

PUMP INTAKES

Pump intakes sit in the foot-well of the spa pool. Water is sucked
through these and then expelled back out the jets.
16

INTERNAL DRAIN

The spa pool water drains out this port when the external drain valve
is released. Small Ozone bubbles may emit from this piece from time
to time - this is a normal function.
17

EXTERNAL DRAIN VALVE

The external drain valve sits on a cabinet panel on one side of the spa
pool. Attach a hose and twist and turn to release the flow of water
when draining. Using the drain valve is explained on page 88.
18

FOUNTAIN

Select models have fountains which pop up and run in conjunction
with the waterfall. They are illuminated with an LED light as part of
the lighting package. It is controlled via the waterfall control dial.
19
TOPSIDE CONTROL PANEL
This is the button pad and temperature display panel located on the
top of the spa pool into which various commands, control sequences
and options for operating the spa pool can be entered.
20
SYSTEM CONTROLLER
The heart of the spa pool. A computer system and heater makes up
the controller as a whole and controls all components in the spa pool
including the topside control panel.
21
HEADREST
Select hydrotherapy seats have headrests as a comfort option to add
to the relaxation experience. Some headrests have LED lights behind
to illuminate the area.
