5. STARTUP & REFILL PROCEDURE

INSTALLING THE FILTER CARTRIDGES - STANDARD WEIR SKIMMER

ENTERTAINER X80 AND ENTERTAINER X90 SPA POOLS.
Filters are found attached to the step box.
1
Make sure the inner skimmer flap
is laying down as per photo.
4
Locate the sliding grill tray.
Take note of how it sits inside the
skimmer for later replacement.
7
Place both filters into the
corresponding holes and find the
thread to screw into.
AVOID DAMAGE TO SPA POOL & VOIDING WARRANTY - ONLY
USE FILTER CARTRIDGES PURCHASED FROM ALPINE SPAS.
18
2
Grip front lid as per photo, and
gently lift upwards (do not pull out
at this stage).
5
Pull the grill tray out towards you.
8
Gently twist clockwise until the
filter is locked in place (do not
use excessive force). Replace the
sliding grill tray.
3
When the inner flap hits the top of
the skimmer box, pull the front lid
outwards.
6
These two holes have threads
at the bottom for your filters to
screw into.
9
Replace the front lid by positioning
the flap in the middle of the
skimmer box, and pressing the
front lid in towards the skimmer
while using downwards pressure.
