7. GETTING TO KNOW YOUR SPA POOL

SPA POOL PARTS LABELED

74
1

AIR VENTURI

Turning this dial injects air into the jet-stream, boosting the pressure
of the jets in a particular set of seats (usually the ones closest to the
dial). Turn dial off when finished with the jets to avoid a continuous
flow of cold air entering the water when you are not soaking.
2

WATERFALL CONTROL DIAL

This smaller three pin valve is used to adjust the flow rate of the
waterfall and fountains (if equipped). To turn off - simply twist
clockwise until fully closed and reverse this process to turn on. Be
careful not to overturn the dial and force it past it's natural stopping
point.
3

PRIMARY DIVERTER

This dial gives you the ability to force maximum jet pressure into a
certain group of seats. Turn it fully left or fully right to transfer water
pressure between different seats in the spa pool. Position it halfway
(50/50) to distribute an even pressure to all seats at once.
4
AROMATHERAPY
Unscrewing the aromatherapy cap provides a slot for your
aromatherapy cannister. When the air-blower runs, the fragrance will
be drawn through the air system and bubbles to the surface of the
water for you to enjoy.
5
MASSAGE JETS
Stainless Steel bearing-less jets come in a variety of sizes and
configurations in your spa pool to deliver a range of different
massage pressures to those persons soaking. Activate by turning on
the jet pump via the topside control panel.
6
AIR JETS
Air jets are located around the bottom of the seats and are activated
by the air blower. Be wary not to over-use the air blower as it will
inject cold air (cooler than the current water temperature) into the
spa pool, cooling the water.
7
LED PERIMETER LIGHTING
There is a perimeter of mini LED lights surrounding the top inner
edge of the acrylic. These can be switched between various colour
options and modes by using the topside control panel. The LED line is
a good indicator of how high your water level should be.
