System Configuration
For your satellite communication system to work properly, the system will have to
be connected with all of the provided components as shown in the figure below.
Separate purchase of a satellite modem, ship's gyrocompass, and Intellian Dual
VSAT Mediator may be required.
Basic System
Configuration
Dual System
Configuration
Antenna Control Unit 1
Antenna Control Unit
Satellite Modem
(Not supplied)
Ship's Gyrocompass
Mediator
(Not supplied)
RX
Satellite Modem
(Not supplied)
Antenna Control Unit 2
MODEM Interface
ACU Interface
PC Interface
INTRODUCTION
Ship's Gyrocompass
(Not supplied)
TX
11
