Intellian v100GX Installation And Operation Manual page 85

Establish a data Access ACU through Serial Communication
communication
1.
2.
3.
4.
5.
Access ACU through Network Communication (TCP/IP)
1.
2.
3.
4.
5.
6.
7.
NOTE: If the remote access PC is located in the same network group with the ACU,
the ACU can be accessed through the internal IP address. But, if the remote access
PC is located outside of the network group, the ACU's IP address should be changed
to the IP address assigned by the network service provider. Refer to page 129 for
changing the ACU's IP address. To change the username and password, refer to page
133.
WARNING:
Connect a 9 pin Serial cable between the PC INTERFACE connector on
the ACU and the 9 pin Serial port on the PC. (Or you can use a USB cable
to setup Serial connection between a PC and the USB port on the ACU.)
Select Serial at communication type combo-box.
The baud rate of the ACU is 57600 for the v100GX.
Select a COM port which is not occupied by other devices.
Click the Connect button.
Turn off the wireless connection while using this method.
Connect your PC to the Management Port. (See page 36 for other network
connection method.)
Select Network at communication type combo-box.
Enter in the ACU's IP address (Factory default : 192.168.2.1)
Enter in the ACU's port number (Factory default : 4002)
- Enter 4003 for SSL Secure Connection.
Click the Connect button then the Authentication window will appear.
Login by using the username and password below:
- Username: intellian (Factory default)
- Password: 12345678 (Factory default)
-
Do not plug a USB to the ACU while TCP/IP communication is in use.
Doing so will disable current PC Software Control because the USB
connection has higher priority than TCP/IP connection.
- The amount of data will increase rapidly if Network Communication is in use.
Intellian recommends using Remote Web Access (Web M&C) to access the
ACU. (refer to page 109).
ANTENNA CONTROL SOFTWARE
