Intellian v100GX Installation And Operation Manual page 68

v100GX – Marine Satellite Communication System
DVB verifiy method
Set LNB local frequency
Set polarity
68
D V B V E R I F Y
D V B D E C O D E
6. Edit satellite DVB VERIFY* method and SKEW OFFSET.
DVB VERIFY will be only activated and applied when DVB mode of TRACKING SIGNAL is
chosen to be used. Touch UP and DOWN arrow keys to select DVB VERIFY and touch OK
key to set the parameter.
DVB VERIFY*
AGC – use signal level for satellite tracking.
DVB Lock – use DVB Lock for satellite tracking.
DVB Decode – use DVB Decode for satellite tracking.
DSS Decode – use DSS Decode for satellite tracking.
S E L E C T L O C A L
1 1 3 0 0 M H Z
7. Set SELECT LOCAL* frequency and TRACKING SIGNAL*.
Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Touch UP and DOWN arrow keys to select the LNB local frequency from the installed LNB.
Or touch NUMBER keys to set the desired value directly. Touch OK key to set the parameter.
SELECT LOCAL*
The selectable LNB frequencies
are depended on the installed LNB
type.
R X P O L
V E R T .
8. Set RX POL and TX POL to select the polarity for both RX (receive) and TX (transmit).
Touch UP and DOWN arrow keys to select VERTICAL or HORIZONTAL.
Touch OK key to set the parameter.
S K E W O F F S E T
+ 0 . 0
T R A C K I N G S I G N A L
N B D
TRACKING SIGNAL*
NBD
DVB
T X P O L
H O R I .
