Basic System Configuration of Intellian Inland
For your satellite TV system to function properly, the system will have
to be connected with all of the provided components as shown on the
right. (Refer to the next chapter 'Installation' in this manual for more
detailed connection instructions). Separate purchase of a satellite
receiver and a TV is required.
6
TV
(Not Supplied)
Satellite Receiver
(Not Supplied)
ACU
FG - +
+ -
DC 24V ANT RF1 RECEIVER NMEA PC INTERFACE
NMEA GPS
Adapter
( AC 110~220V )
Figure 1 : Basic Configuration
TV
(Not Supplied)
Satellite Receiver
(Not Supplied)
PC (Not Supplied)
