System Settings

Set LNB Local Oscillator Frequency
Y E S
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ A N T E N N A
+ S Y S T E M
2. Touch DOWN arrow key to move cursor to SYSTEM and touch OK key to enter it.
+ S E T L O C A L
+ M O D E M P O R T
3. Touch OK key to enter SET LOCAL menu to set the LNB local frequency.
1 3 V + 0 K H Z
1 0 0 0 0 M H Z
1 3 V + 2 2 K H Z
1 0 7 5 0 M H Z
4. Set LNB local oscillator frequency for each correspondent voltage power.
(13V +0 kHz, 18V +0 kHz, 13V +22 kHz, 18V +22 kHz)
Touch BACK key and Touch LEFT and RIGHT arrow keys to select the parameter you wish to
edit. Touch OK key to edit parameter. Or touch BACK key again to return to the main display.
LNB LOCAL: The selectable LNB frequencies are depended on the installed LNB type.
Y E S
5. Touch LEFT arrow key to move cursor to YES and touch OK key to save current settings.
Or move cursor to NO and touch OK key to abort and return to the main display.
S E T U P M O D E ?
+ S A T E L L I T E
+ I N S T A L L A T I O N
+ S E T L O C A T I O N
+ M A N A G E M E N T
S A V E ?
OPERATING THE ACU
N O
1 8 V + 0 K H Z
1 1 3 0 0 M H Z
1 8 V + 2 2 K H Z
0 9 7 5 0 M H Z
N O
