Serial/USB Connection
Connection through Serial Port
Serial Connection
1. Connect a 9-pin Serial cable from the PC INTERFACE connector on the
2. If there is not a 9-pin serial port on the PC, use a USB-Serial adapter.
3. To access Intellian Aptus
USB Connection
Connection through USB Port
There are two USB(USB-to-Serial) ports are available on the ACU. One is on the
front and the other is on the rear.
1. Connect a USB cable from a USB port on your PC to the USB port
on the ACU.
2. To access Intellian Aptus
Note: The v100GX also supports Wi-Fi connection between PC and the ACU and
Bluetooth connection between PC and the antenna. To setup Wi-Fi or Bluetooth
connection, refer to page 38 and 145, respectively.
ACU to the 9-pin serial port on your PC.
, see page 85.
®
, see page 85.
®
