Set modem protocol
Use TX mute
M O D E M P O R T
E T H E R N E T
5. MODEM PORT* is to select a proper data communication port on the ACU to interface
with the modem.
PROTOCOL* is to select a proper communication protocol on the ACU to interface with the
modem.
MODEM PORT*
ETHERNET
RS422
RS232
PROTOCOL*
I/O CONSOLE: is a protocol for interchanging of information (GPS Out, TX mute, and
modem lock) between the ACU (through Console port) and a modem.
OPEN AMIP: is an ASCII based protocol developed by iDirect for interchanging of
information between the ACU and a modem. OpenAMIP is not intended for any purpose
except to allow the ACU and a modem to perform synchronized automatic beam
switching (ABS).
SERIAL GPS: is a protocol for sending GPS Out information from the ACU (through
RS232/422 port) to a modem.
ROSS: ROSS Open Antenna Management (ROAM) protocol is developed by Comtech
EF Data Cooperation to offer common management interface for Comtech EF Data's
Roaming Oceanic Satellite Server (ROSS) and ACU.
VCAP: is the interface between the SatLink mobile VSAT IDU and the Intellian antenna
controllers for Intellian mobile antennas.
G P S O U T S E N T E N C E
G P G L L
6. GPS OUT SENTENCE* is to select the GPS OUT SENTENCE type USE TX MUTE is
to select whether or not to USE TX MUTE function from the satellite modem. A transmit
inhibit output from the ACU will disable/mute the modem transmit via a voltage whenever the
antenna is blocked, searching, or is mis-pointed 0.5 degrees from the peak satellite position.
GPS OUT SENTENCE*
GPGLL
GPGGA
SIMPLE GPGGA
OPERATING THE ACU
P R O T O C O L
I / O C O N S O L E
U S E T X M U T E
Y E S
