v100GX – Marine Satellite Communication System
Setup mode
Installation
menu
Select satellite
Latitude & Longitude
Gyro type
52

Installation Settings

During the first time installation, it is required to setup the installation settings.
Y E S
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode
+ A N T E N N A
+ S Y S T E M
2. Touch arrow keys to move cursor to INSTALLATION menu and touch OK key to enter it.
[ 1 ] T E L S T _ 1 8 1 3 8 . 0 0 E
3. Touch UP and DOWN arrow keys to select the satellite that you wish to track and touch
OK key to load the selected satellite.
L A T I T U D E
3 7 . 0 0 N
4. Set the current LATITUDE and LONGITUDE
Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Touch UP and DOWN arrow keys to increase or decrease the value. Or touch NUMBER keys
to set the desired value directly. Touch OK key to set the parameter.
G Y R O T Y P E
N M E A
5. Set the ship's GYRO TYPE* & BOW ADJUST
A search pattern 1 or 3 will be initiated according to which Gyro Type is selected and the
existence of the gyro input. Ensure that the supported Gyro Type is set correctly. For v100GX,
If the ship's gyrocompass output is different than NMEA, A search pattern 1 will be initiated
automatically if the gyro input does not exist and the gyro type that is selected is different
than GROUND TEST.
The BOW ADJUST is to offset the angle difference between the antenna's bow and the ship's
bow (Range: 0 – 360°).
NOTE: The bow offset will not be saved automatically if Search 1 pattern is initiated. In this case, the
antenna will need to retarget the desired satellite using Search 1 every time if the antenna restarts.
S E T U P M O D E ?
+ S A T E L L I T E
+ I N S T A L L A T I O N
S E L E C T S A T E L L I T E
N O
L O N G I T U D E
1 2 6 . 5 3 E
B O W A D J U S T
0 0 0
