Installation Kit
Contains the items required for securing the antenna unit and ACU to the vessel.
Antenna Q'ty
5
5
5
10
5
5
ACU Q'ty
5
10
5
Other Components
Item Image
1
2
Description
Hex. Bolt
Flat Washer
Spring Washer
Hex. Nut
Hex Head
Wrench Bolt
Dome Washer
Description
Self-Tapping
Screw
Flat Head Screw
Sems Bolt
Q'ty Description
2 Rack
ACU
Bracket
2 Table
1 RG6 Cable
Size Remark
M12 x 80L
M12
Antenna-Deck
4 Sets: Installation
1 Set: Spare
M12
M12
M6 x 40L
Radome
(Spare Blots)
M6
Size Remark
Table Mount
M4 x 16
Bracket
Rack Mount
M4 x 12L
Bracket ACU
Table Mount
M3 x 12L
Bracket ACU
Size Remark
- ACU-19inch Rack
- ACU-Table
3m ACU to Modem
