Intellian v100GX Installation And Operation Manual page 76

v100GX – Marine Satellite Communication System
Setup mode
System menu
Modem port menu
Set Mediator &
modem type
76
Set Modem Port
Y E S
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ A N T E N N A
+ S Y S T E M
2. Touch DOWN arrow key to move cursor to SYSTEM menu and touch OK key to enter it.
+ S E T L O C A L
+ M O D E M P O R T
3. Touch DOWN arrow keys to move cursor to MODEM PORT menu and touch OK key to
enter it.
U S E M E D I A T O R
N O
4. USE MEDIATOR is to enable the usage of MEDIATOR if the antenna is connected to the
Intellian Dual VSAT Mediator.
USE MEDIATOR must be disabled if there is no MEDIATOR connected to the
NOTE:
ACU. Improper setting of this parameter will cause your ACU's modem interface
working incorrectly.
MODEM TYPE* is to select a proper data communication port and protocol on the ACU to
interface with the satellite modem. The settings related to the modem interface will be set
automatically once the modem type is selected.
The options on the next page will be displayed and required to be set if "USER SETTING" is
selected.
MODEM TYPE*
USER SETTING
IDIRECT-I/O
IDIRECT-AMIP
COMTECH-I/O
COMTECH-ROSS
HUGHES
SATLINK-SERIAL
SATLINK-VACP
S E T U P M O D E ?
+ S A T E L L I T E
+ I N S T A L L A T I O N
+ S E T L O C A T I O N
+ M A N A G E M E N T
M O D E M T Y P E
I D I R E C T - I /O
N O
