Conventions

Table 3 provides the conventions used for the ON and OFF settings in the present document.
Convention
Jumper JPx ON
Jumper JPx OFF
Jumper JPx [1-2]
Solder bridge SBx ON
Solder bridge SBx OFF
Resistor Rx ON
Resistor Rx OFF
UM2488 - Rev 4
Table 3. ON/OFF convention
Jumper fitted
Jumper not fitted
Jumper should be fitted between Pin 1 and Pin 2
SBx connections closed by 0 Ω resistor
SBx connections left open
Resistor soldered
Resistor not soldered
Definition
