UM2488
STM32H745I-DISCO and STM32H750B-DK layout
Figure 5.
STM32H745I-DISCO and STM32H750B-DK Discovery board bottom layout
CN12, CN16 Arduino
connectors
CN15 USB power
connector
CN14 STLK USB
connector
CN1 Ethernet
connector
JP8 power
header
CN3, CN7 Arduino
connectors
CN13 USB OTG_FS
connector
U6 MCU
U21, U22
FDCANs
U7 SDRAM
U11 eMMC
U1, U2 QSPI
CN8 line in
connector
CN9 line out
connector
P1 STMod+
CN14 STDC14
U15 Audio
connector
connector
Codec
UM2488 - Rev 4
page 9/55
