Ensure that the supply and return connections are correct.
If you will not use the laser for a long time, water must be emptied from the product, and then
both the inlet and outlet must be blocked with the nuts we provide. Failure to do so may lead to
permanent equipment damage.

3.3 Installation Procedure

(1) Check if the power supply has the correct voltage (230VAC±10%，50/60Hz), and the earth
line is connected, make sure it is firm and reliable;
(2) Place the product in an appropriate position, immobilize it if necessary;
(3) Connect the power cable and control cable to the product when power supply is OFF;
(4) Insert the water pipes into the inlet and outlet;
(5) Check the output head and clean it if necessary. This procedure must be performed by
Raycus personnel or person authorized by Raycus. Make sure the environment is clean, or
the output head may be contaminated. It is prohibited to use fan during installation, which
will cause dust in the air;
(6) Prevent the delivery cable from treading, pinching or excessive bending during installation;
CAUTION: Please set the water temperature in strict accordance with the
requirements above. Too low temperature may lead to condensation on the
laser module and the output head. This can cause serious damage to the
equipment.
CAUTION: The cooling system should be turned on first. Check any
water leakage and make sure that the water temperature reaches the set
point before you start the laser.
