PE-Protective Earth

4.4 Interface Definitions

4.4.1 Service
The service port is in Figure 13
The pin definitions are shown in Table 6.
PIN NO. DESCRIPTION
1 24V1
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
Figure 12: Lock the Plug With the Lever
Figure 13: Pin Number of Service Port
Table 6: Pin Definitions of Service Port
If the main switch is turned on, and Pin 1 and Pin 2 are shorted,
the laser will start, and when Pin 1 and Pin 2 are open, the laser
11
User Guide 100W~750W Ver: 1.0
NOTE
