    Installation: To install each accessory, use the installation guide provided with it, or download the guide from our Web site at humminbird.com. Compatibility: This guide covers HELIX 9, 10, and 12 operations with AIS. Visit our Web site at humminbird.com for the most current list of AIS-compatible Humminbird models.
  • Page 6 Open the AIS Menu 1. Main Menu: Press the MENU key twice. Select the Accessories tab. 2. Select AIS. 3. Press the RIGHT Cursor key. Turn on Tracking Target Tracking Target must be turned on to display AIS targets in the Chart View, Bird’s Eye View, and the Target List. 1.

  • Page 7: Ais Target Overview

    AIS T ARGET VERVIEW Each target is represented by an icon that indicates the vessel type and whether it is tracked, lost, or triggering an alarm. Tracking: Targets within the range of the AIS VHF signal are identified and sending information to the AIS. Lost: If the AIS has not received information from a target in the last 10 minutes, the target icon status will change to lost.

  • Page 8: Turn On Alarms

    URN ON LARMS Use CPA Limits to set how close targets may approach your vessel. The amount can be set in nautical miles or time. When the target has traveled past the set limit, the target icon will turn red and an alarm will sound on the control head (as determined by your control head sound settings).

  • Page 9: Display Ais Target Information

    AIS T ISPLAY ARGET NFORMATION You can select targets from the Target List or the Chart View. The Target List displays a summary of each tracked target. In the Chart View, you can view details about a selected target. Display the Target List The Target List displays the list of available targets with MMSI (Maritime Mobile Service Identity), COG (Course over Ground), Speed, and TCPA (Time to Closest Point of Approach).
  • Page 10 Display Details for a Selected Target You can select a target from the Target List or the Chart View. 1. Select a target from the Target List. Press the RIGHT Cursor key. Use the Cursor Control key to move the cursor to a target on the Chart View. 2.

  • Page 11: Navigate To A Selected Target

    Displaying Target Details AVIGATE TO A ELECTED ARGET Start Navigation to a Selected Target 1. Select a target from the Target List. Press the RIGHT Cursor key. Use the Cursor Control key to move the cursor to a target on the Chart View. 2.

  • Page 12: Change Target Display Settings

    HANGE ARGET ISPLAY ETTINGS You can customize how targets are displayed in the Chart View. The display settings in this section do not apply to AIS targets in the Bird’s Eye View. Adjust the Target Course Line The target course line shows the direction of a target’s course. The Target Course Line menu sets the amount of time represented on the target course line.

  • Page 13: Contact Humminbird

    ONTACT UMMINBIRD Contact Humminbird Customer Service in any of the following ways: Web site: humminbird.com E-mail: service@humminbird.com Telephone: 1-800-633-1468 Direct Shipping: Humminbird Service Department 678 Humminbird Lane Eufaula, AL 36027 USA Hours of Operation: Monday - Friday 8:00 a.m. to 4:30 p.m. (Central Standard Time) Social Media Resources: Facebook.com/HumminbirdElectronics...
