Key Name
POWER key
ENTER key
EXIT key
GO TO &
Screen
Snapshot key
PANE key
MARK &
Man Overboard
key
HOME key
ZOOM In key
ZOOM Out key
MENU key
Key Press Function(s)
Powers on the control head.
During operation, this key opens the Power X-Press Menu.
Starts a command.
Selects, or turns on, a setting.
Opens menus.
Opens the Info menu and the Cursor menu.
Closes an open menu or dialog box.
Turns off an alarm.
Exits Cursor mode.
Returns to the last displayed view from the Home screen.
Opens the Go To menu for navigation functions (see
Routes for details).
Activates the Side Bar (the side bar is highlighted in
yellow). Use the Joystick to scroll through the side bar
widgets.
Selects a pane in a multi-pane view (the selected pane
is highlighted in yellow. See Views.)
Press TWICE to mark waypoints.
Displays the Home screen. See The Home Screen.
Changes the scale of the view to show a closer
perspective.
Changes the scale of the view to show a wider view.
Opens the X-Press Menu for the on-screen view and
operation mode.
Press TWICE to open the Settings tool.
9
Key Press Function(s)
Powers off the control head.
Adjusts menu settings.
May vary with the displayed view.
Closes all open submenus and
menus.
Screen Snapshot: Saves the
on-screen view (image). See
Images Tool.
Man Overboard: Starts Man
Overboard (MOB) Navigation. See
Man Overboard (MOB) and
Introduction to Navigation).
Zoom out all the way.
Returns to the last-used Settings
tool tab. See The Menu System.
