VLT AutomationDrive FC 300 Operating
Instructions
No. Description
61 Tracking Error
62 Output Frequency at Maximum Limit
63 Mechanical Brake Low
64 Voltage Limit
65 Control Board Over-temperature
66 Heat sink Temperature Low
67 Option Configuration has Changed
68 Safe Stop
69 Pwr. Card Temp
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous Failure
73 Safe Stop Auto Restart
77 Reduced power mode
79 Illegal PS config
80 Drive Initialized to Default Value
81 CSIV corrupt
82 CSIV parameter error
85 Profibus/Profisafe Error
90 Encoder Loss
91 Analogue input 54 wrong settings
100-
See Operating Instructions for MCO 305
199
243 Brake IGBT
244 Heatsink temp
245 Heatsink sensor
246 Pwr.card supply
247 Pwr.card temp
248 Illegal PS config
250 New spare part
251 New Type Code
Table 6.2: Alarm/Warning code list
(X) Dependent on parameter
1) Can not be Auto reset via Par 14-20
A trip is the action when an alarm has appeared. The trip will coast the
motor and can be reset by pressing the reset button or make a reset by
a digital input (Par. 5-1* [1]). The origin event that caused an alarm can-
not damage the frequency converter or cause dangerous conditions. A
trip lock is an action when an alarm occurs, which may cause damage to
frequency converter or connected parts. A Trip Lock situation can only be
reset by a power cycling.
LED indication
Warning
Alarm
Trip locked
Warning
(X)
X
X
X
X
(X)
X
X
(X)
X
X
yellow
flashing red
yellow and red
MG.33.AB.02 - VLT is a registered Danfoss trademark
Alarm/Trip Alarm/Trip Lock
(X)
(X)
X X
X
(X) 1)
X X
X
1)
X
1)
X
X X
X
(X)
X
X
X X
X X
X X
X X
X X
X
X X
6. Troubleshooting
Parameter
Reference
4-30
2-20
5-19
5-19
5-19
14-59
6
17-61
S202
14-23
83
