VLT AutomationDrive FC 300 Operating
Instructions
Digital output:
Programmable digital/pulse outputs
Terminal number
Voltage level at digital/frequency output
Max. output current (sink or source)
Max. load at frequency output
Max. capacitive load at frequency output
Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Resolution of frequency outputs
1) Terminal 27 and 29 can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Analog output:
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load GND - analog output
Accuracy on analog output
Resolution on analog output
The analogue output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 V DC output:
Terminal number
Output voltage
Max. load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital inputs and outputs.
Control card, 10 V DC output:
Terminal number
Output voltage
Max. load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, RS 485 serial communication:
Terminal number
Terminal number 61
The RS 485 serial communication circuit is functionally separated from other central circuits and galvanically isolated from the supply voltage (PELV).
Control card, USB serial communication:
USB standard
USB plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB ground connection is not galvanically isolated from protection earth. Use only an isolated laptop as PC connection to the USB connector on
the frequency converter.
Relay outputs:
Programmable relay outputs
Relay 01 Terminal number
1)
Max. terminal load (AC-1) on 1-3 (NC), 1-2 (NO) (Resistive load)
MG.33.AB.02 - VLT is a registered Danfoss trademark
5. General Specifications
27, 29
0 - 24 V
40 mA
1 kΩ
10 nF
0 Hz
32 kHz
Max. error: 0.1 % of full scale
12 bit
42
0/4 - 20 mA
500 Ω
Max. error: 0.5 % of full scale
12 bit
12, 13
24 V +1, -3 V
FC 301: 130 mA/ FC 302: 200 mA
50
10.5 V ±0.5 V
15 mA
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
1.1 (Full speed)
USB type B "device" plug
FC 301 ≤ 7.5 kW: 1 / FC 302 all kW: 2
1-3 (break), 1-2 (make)
240 V AC, 2 A
2
1)
5
1
