3. How to Install
Mains connector A5 (IP 55/66) Enclosure
3
When disconnector is used (A5 enclosure) the PE must be mounted on the left side of the drive.
Illustration 3.3: Mains connection B1 and B2 (IP 21/NEMA Type 1 and
IP 55/66/ NEMA Type 12) enclosures.
Illustration 3.5: Mains connection B4 (IP20) enclosure.
22
Illustration 3.4: Mains connection B3 (IP20) enclosures.
Illustration 3.6: Mains connection C1 and C2 (IP 21/ NEMA Type 1 and
IP 55/66/ NEMA Type 12) enclosures.
MG.33.AB.02 - VLT is a registered Danfoss trademark
®
