3. How to Install
3
Frame size
IP
NEMA
Height
Height of back plate
Height with de-coupling plate
Distance between mounting
holes
Width
Width of back plate
Width of back plate with one C
option
Width of back plate with two C
options
Distance between mounting
holes
Depth
Depth without option A/B
With option A/B
Screw holes
Max weight
14
A1
A1
0.25–1.5 kW
(200-240 V)
0.37-1.5 kW
(380-480 V)
20
Chassis
A 200 mm
A 316 mm
a 190 mm
B 75 mm
B
B
b 60 mm
C 207 mm
C 222 mm
c 6.0 mm
d ø8 mm
e ø5 mm
f 5 mm
2.7 kg
MG.33.AB.02 - VLT is a registered Danfoss trademark
VLT
Mechanical Dimensions, A enclosures
A2/ A3
A2
0.25-3 kW
(200-240 V) (200-240 V)
0.37-4.0 kW 5.5-7.5 kW
(380-480/ 500 V) (380-480/ 500 V)
0.75-4 kW 5.5-7.5 kW
(525-600 V) (525-600 V)
20 21 20
Chassis Type 1 Chassis
268 mm 375 mm 268 mm
374 mm 374 mm
257 mm 350 mm 257 mm
90 mm 90 mm 130 mm
130 mm 130 mm 170 mm
150 mm 150 mm 190 mm
70 mm 70 mm 110 mm
205 mm 207 mm 205 mm
220 mm 222 mm 220 mm
8.0 mm 8.0 mm 8.0 mm
ø11 mm ø11 mm ø11 mm
ø5.5 mm ø5.5 mm ø5.5 mm
9 mm 9 mm 9 mm
4.9 kg 5.3 kg 6.6 kg
®
AutomationDrive FC 300 Operating
A5
A3 A5
3.7 kW 0.25-3.7 kW
(200-240 V)
0.37-7.5 kW
(380-480/ 500 V)
0.75-7.5 kW
(525-600 V)
21 55/66
Type 1 Type 12
375 mm 420 mm
- -
350 mm 402 mm
130 mm 242 mm
170 mm 242 mm
190 mm 242 mm
110 mm 215 mm
207 mm 195 mm
222 mm 195 mm
8.0 mm 8.25 mm
ø11 mm ø12 mm
ø5.5 mm ø6.5 mm
9 mm 9 mm
7.0 kg 13.5/14.2 kg
