Installation
Door LED
Mode LED
3 x 4 Matrix Keypad
Bell Button
Case Screw
6. Wire the controller according to the diagrams on the next
few pages.
7. Return and secure the front case using the security screw
and security tool provided in the Installation Kit.
You have now mechanically installed the controller.
Page 11
Figure 1: Mounting the Controller
AC-115 Hardware Installation and User's Guide
MODE
DOOR
1
2
3
4
5
6
7
8
9
0
#
