Service Manual – SC401, SCRUBTEC 344
Rear/Left Machine View
Recovery tank
cover
Recovery tank
Tank lifting
handle
Solution drain
and level check
hose
Brush deck
lifting/lowering
pedal
Front wheels
Figure 4:
03 - General Information
Drive handlebar
Control panel
Recovery water
drain hose
Battery charger
cable
Battery charger
cable housing
and document
holder
Serial number
plate/technical
data/conformity
certification
Battery
connector (red)
Squeegee
vacuum hose
Squeegee lifting/
lowering pedal
Squeegee
adjusting knob
Squeegee
mounting
handwheels
20
