Service Manual – SC401, SCRUBTEC 344
Main Machine Controller (EB1) Connectors (continues)
J403 OUT2: type FCI T702035100J0G (2 ways, screw type)
PIN Description
Vacuum output +
1
Vacuum output -
2
Figure 26:
J601 AUX1: type JST B2P-VH (2 ways, vertical)
PIN Description
Solenoid valve output +
1
Solenoid valve output -
2
Figure 27:
+
-
1 2
Controller
V ref.
in/out
Out 24V
Out 0V
Controller
V ref.
in/out
Out 24V
Out 0V
04 - Control System - Battery
I max. Connected to
M2+
15A
M2-
15A
I max. Connected to
EV+
1A
EV-
1A
