Service Manual – SC401, SCRUBTEC 344
User Interface Controller (EB2) Connectors (continues)
RIGHT: JST S3B-ZR-SM4A-TF (3 ways, side entry)
PIN Description
Right operator presence sensor supply -
1
Right operator presence sensor supply +
2
Right operator presence sensor input
3
Figure 39:
Controller
in/out
out
out
In
1 2 3 1 2 3
04 - Control System - Battery
V ref. I max.
0V
<1A
5V
<1A
0V
<1A
54
Connected to
S2.1
S2.2
S2.3
