Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
4
Initial Switch Administration: G3i/G3s/G3vs/R5vs/R5si/ProLogix
Administering the Digital Networking Port (Optional)
The switch displays the first page of the Station screen.
2. Enter y in the Data Module field.
This adds a Data Module screen for the station.
3. Press
change station 31001
DATA MODULE
Data Extension: 31024
ITC: restricted
ABBREVIATED DIALING
List:
SPECIAL DIALING OPTION
ASSIGNED MEMBER ( Station with a data extension button for this data module )
Ext
1:
Figure 4-18. Example of a Station Screen Data Module Page
4. Change each of the following fields as indicated:
until the Data Module screen displays.
NEXTPAGE
STATION
Name
Data Extension field - enter a unique extension from the switch
dialing plan.
Name field - enter a name that identifies the networking port.
COR field - enter a value for COR in which:
— Data Privacy = y
— Calling party restriction = N
— Called party restriction = N
— The FRL is greater than or equal to the FRL of the trunk
Name: networking port 1
COS: 1
COR: 1
TN: 1
Issue 1
May 1999
4-36
Page 6 of 6
SPE B
BCC: 2
