Lucent Technologies DEFINITY AUDIX Installation And Administration Manual page 260

Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
J Analog Port Administration
Administering the Voice Ports as Stations
Table J-2. Station Screen Entries (G3i/G3s/G3vs/R5si/R5vs or greater) — Continued
Field
COR
Port
Security Code
COS
Name
Coverage Path
Tests?
LWC Reception?
LWC Activation?
SMDR Privacy?
Redirect
Notification?
Off Premise
Station?
Entry
A Class of Restriction for the voice port that reflects the desired
restriction. The COR should provide security for the voice ports.
Obtain the COR from Worksheet B-5 in
Enter the port equipment location of the DEFINITY AUDIX TN568
circuit pack on the switch. Enter six characters (for example,
1A0501). Obtain the port number from Worksheet B-5 in
The first character identifies the cabinet (1, 2, or 3; default is 1).
The next character identifies the carrier (A, B, C, D, or E).
The next two characters identify the slot number in the carrier (01
to 18 for G3s/G3i/R5si with a single-carrier cabinet and 01 to 20
for G3i/R5si with a multicarrier cabinet; 01 to 10 for G3vs/R5vs).
The DEFINITY AUDIX system occupies two slots in the switch
(one slot if the system is installed in slot 6 of a Prologix cabinet).
Enter the number of slot 2. Slot 2 is occupied by the TN568
circuit pack.
The last two characters identify the circuit number. Valid entries
are 01 to 12. Assign the first voice port to circuit 01, the second
to circuit 02, etc.
Leave this field blank.
Enter a Class of Service (COS) that allows access only to the
features Call Forwarding All Calls and Data Privacy (indicated by y).
All other features for the COS should be set to n. Obtain this from
Worksheet B-5 in Appendix
Enter AUDIX x where x equals the circuit number of the port, or enter
any other name. Obtain the name from Worksheet B-5 in
B.
Leave this field blank.
n
none
n
n
n
n
Appendix
B.
Continued on next page
Issue 1
May 1999
J-6
B.
Appendix B.
Appendix
