1 Prerequisites
Verify the Components and Connectivity
DEFINITY AUDIX
TN568 circuit pack
Magneto-
Hard
disk drive
drive
D8W
104A
Demarcation
Point
Figure 1-2. DEFINITY AUDIX LAN Connectivity
NOTE:
If DEFINITY AUDIX is to be used as a server for LAN applications such as
I
NTUITY
LAN within 25 feet of the switch. The customer is responsible for the
connection between the LAN and the connecting block.
Figure 1-2
to a LAN. For both choices, the RJ45 connector on the system adaptor cable
connects to a 10BaseT LAN system. Further details are provided in
Connection''
optical
10BaseT
(twisted pair)
10BaseT
(twisted pair)
Message Manager, Lucent must install a connecting block for the
shows two possible ways of connecting the DEFINITY AUDIX system
on page 2-10.
BALUN
Ethernet coaxial cable
LAN server
LAN server
10BaseT
hub
May 1999
INTUITY
Message Manager
client software
INTUITY
Message Manager
client software
cydxalan AWF 021899
''LAN
Issue 1
1-5
