I Changing Switch Integrations, Port Emulations, and Number of Voice Ports
Decreasing the Number of Digital Voice Ports from 12 to 8
Decreasing the Number of Digital Voice Ports
from 12 to 8
To add a digital networking port to a system that already uses digital port
emulation, you may need to decrease the total number of ports. On a switch to
which you are adding a networking port, the number of voice ports may be no
greater than 8.
To decrease the number of digital voice ports, do the following tasks:
Change the Voice Group screen on the DEFINITY AUDIX system
Verify DEFINITY AUDIX Customer Options
Add Networking Ports
Remove Ports from the Hunt Group
Changing the Voice Group Screen on the
DEFINITY AUDIX System
To remove the voice ports on the DEFINITY AUDIX system, change the Voice
Group screen.
To change the Voice Group screen:
1. On the DEFINITY AUDIX command line, enter change voice-group
The Voice Group screen appears.
2. Delete voice ports 9 and above.
Verifying DEFINITY AUDIX Customer Options
To verify the DEFINITY AUDIX customer options:
1. Log into the DEFINITY AUDIX system.
2. On the DEFINITY AUDIX command line, enter display
system-parameters customer-options
The system displays the System Parameters Customer Options screen.
3. Check the Maximum Number of Voice Ports field for the new number
of ports.
4. Check the Maximum Number of Digital Networking Ports field
for the number of ports (one).
5. If these values are not correct in one or both of the fields, call the remote
service center immediately to change the values.
