J Analog Port Administration
G3i/G3s/G3vs/R5si/R5vs
Analog Port Administration
This appendix describes the tasks needed to administer analog port emulation.
Analog port emulation was used in DEFINITY AUDIX releases 2.0, 3.0, and 3.1
when control link integration was desired. With DEFINITY AUDIX 4.0, digital port
emulation can be used with both display set integration and control link
integration. These procedures are included here for those customers who may
have upgraded to release 4.0, but did not change from analog port emulation to
digital port emulation.
G3i/G3s/G3vs/R5si/R5vs
This section includes the procedures for administering analog port emulation
with G3i/G3s/G3vs/G3r/R5si/R5vs/R5r switches.
Task J-1: Identifying the Circuit Pack
— Analog Emulation
Use the following procedure to administer the circuit pack:
1. At the switch administration terminal, enter change circuit-packs cabinet
to administer the DEFINITY AUDIX circuit pack on the switch; or, enter
display circuit-packs cabinet to ensure that the switch has recognized
the installed circuit pack.
The switch displays the Circuit Pack screen.
