Lucent Technologies DEFINITY AUDIX Installation And Administration Manual page 125

Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
6 Optional Switch Feature Administration
Switch Recorded Announcement
1. At the switch administration terminal, enter change announcements
2. Enter change hunt-group XX where XX equals the DEFINITY AUDIX
system hunt group number.
3. Record the announcement.
a. On a vacant line (1 to 64), set Ext. to the extension number. The
number must agree with the dial plan.
b. Set Type:
If a TN750 is used, type integrated
If you enter integrated, you must complete the Pro (protect)
and Rate fields.
If customer-provided external equipment is used, type
analog
If you enter analog, you must complete the Queue Length
and Port fields. The Queue Length field applies only if y is
entered in the Queue field.
c. Set COR to the desired class of restriction.
d. Set TN to the Tenant Partition Number.
e. Set Name. (You can use up to 15 characters to describe the
announcement message.)
f. Set Q (queue) to y
g. Set Pro (protect) or QLen (queue length):
If a TN750 Announcement circuit pack is used, set Protect
(integrated) to n
If customer-provided external equipment is used, set Queue
Length (analog) to a number from 1 to 150.
h. If you entered integrated, set Rate to specify the recording speed
when recording announcements on the TN750B Announcement
circuit pack. Valid entries are 16, 32, or 64.
i. Set Port to the equipment location.
j. Press .
ENTER
a. Set First Ann. Extension to the extension of the
announcement system.
b. Set First Announcement Delay (sec) to 5
c. Press .
ENTER
For a TN750 Announcement circuit pack, dial the announcement's
extension number from the console or from a voice terminal with a
console class of service (COS).
Issue 1
May 1999
6-7
