Lucent Technologies DEFINITY AUDIX Installation And Administration Manual page 62

Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
4 Initial Switch Administration: G3i/G3s/G3vs/R5vs/R5si/ProLogix
Identifying the DEFINITY AUDIX Circuit Pack
display circuit-packs 2
CABINET: 2
Slot Code
00:
01:
02:
03:
04:
05:
06:
07::
08: ADX12D
09: TN568
10: TN762 B
'#' indicates circuit pack conflict.
Figure 4-2. Example of a Circuit Pack Screen with TN2181 Emulation (R7si)
2. Check that the values listed on the screen correspond to the value in the
table below.
Table 4-6. Circuit Pack Screen Entries
Field
Slot
Code
CIRCUIT PACKS
Sfx Name
RESERVED-AUDIX-12D
MULTI-FUNCTION
HYBRID LINE
Description
The port slot in which the DEFINITY AUDIX circuit board
resides. The DEFINITY AUDIX circuit board occupies the
second slot of the two port slots occupied by the system. (The
circuit board occupies the first port slot if installed in Slot 6 of
a CMC cabinet).
The circuit pack identification code in the slot occupied by the
TN568 circuit pack (second slot).
TN2181 for G3V2/V3/V4/R5/R6
TN568 for R7 or greater
The switch populates the remaining information, if any, for the
first slot.
CARRIER: E
CARRIER Type: port
Slot Code Sfx Name
11:
12: TN465 B CO TRUNK
13: TN464 C UDS1 INTERFACE
14: TN754 B DIGITAL LINE
15: TN754 B DIGITAL LINE
16:
17:
18:
19:
20:
21:
Issue 1
May 1999
Page 5 of 5 SPE B
4-8
