680 Synergy Plus – Digital Weight Indicator
Table 8-2 lists the default 680 print formats:
Format
GFMT GROSS<G><NL2><TD><NL>
GROSS<G><NL>TARE<SP><T><NL>NET<SP2><N>
NFMT
<NL2><TD><NL>
ACUMFMT ACCUM <A><NL><DA> <TI><NL>
STPTFMT <SCV><SP><SPM><NL>
HDRFMT1-2 COMPANY NAME<NL>STREET ADDRESS<NL>CITY ST ZIP<NL2>
The <G2>, <N2> and <T2> tokens
Note
on the indicator.
The 1000 character limit of each print format string includes the output field length of the print formatting tokens, not
the token length. For example, if the indicator is configured to display a decimal point, the <G> token generates an
output field of 13 characters: the 10 character weight value (including decimal point), one space, and a two-digit units
identifier.
PT (preset tare) is added to the tare weight if tare was keyed in.
8.2

Customizing Print Formats

The GFMT, NFMT, ACUMFMT, STPTFMT and HDRFMT formats can be customized using the print format menu ( PForMT ) via
the front panel. See Section 4.4.6 on page 33
must be in setup mode (Section 4.1 on page
8.2.1

Using the Front Panel

Use the print format menu to customize the print formats and to edit the print format strings by changing the ASCII characters in
the format string. See Section 3.3.2 on page 16
Some characters cannot be displayed on the 680 front panel, see the ASCII character chart in
Note
for available characters. The 680 can send or receive ASCII characters; the character printed depends on the
particular ASCII character set implemented for the receiving device.
54 Visit our website
Default Format String
Table 8-2. Default Print Formats
(Table 8-1) print the gross, net and tare weights in the units not currently displayed
for the print format menu structure. To access the print format menu the indicator
22).
for the alphanumeric entry procedure to edit the print format string.
www.RiceLake.com
When Used
–
Weigh mode no tare in system
–
Weigh mode tare in system
Accumulator demand print format string
Setpoint print operation with PSHPRNT=ON
Section 11.9 on page 69
