7.11 Print Format Commands

Command
GFMT Gross demand print format string
GFMT.PORT
GFMT.PORT2
NFMT Net demand print format string
NFMT.PORT
NFMT.PORT2
ACCFMT Accumulator print format string
ACC.PORT
ACC.PORT2
SPFMT Setpoint print format string
SPFMT.PORT
SPFMT.PORT2
HDRFMT1 Ticket header format strings
HDRFMT2
AUD.DEST1 Audit trail port
AUD.DEST2

7.12 Digital I/O Commands

Command
DIO.b#s Sets DIO type
Valid bit values (b) are 1-4; For commands ending with #s, s is the slot assigned to the digital I/O (0); Slot 0 is onboard

7.13 Analog Output Commands

Command
ALG.SOURCE#s Analog output source
ALG.MODE#s Mode
ALG.OUTPUT#s Type of output
ALG.ERRACT#s Error action
ALG.MIN#s Minimum value tracked
ALG.MAX#s Maximum value tracked
For commands ending with #n, n is the slot number assigned to the analog output (1)
Description
Each format can be sent out one or two ports; for the .PORT and .PORT2 commands,
specify the port name as one of the following: RS232-1, RS232-2, RS485, TCPC, USB,
NONE
Example: To send the Gross format out both RS-232 Port 2 and the TCPC Port at the same
time, send:
GFMT.PORT=RS232-1
GFMT.PORT2=USB
See Section 8.0 on page 53
Table 7-11. Print Format Commands
Description
OFF (default), OUTPUT, PRIM, PRINT, SEC, TARE, UNITS, ZERO, BATRUN,
BATSTRT, BATPAUS, BATRESET, BATSTOP, CLEAR, CLRACC, CLRCN, CLRTAR,
DSPACC, DSPTAR, GROSS, KBDLOC, NET, NT/GRS
Table 7-12. Digital I/O Commands
Description
Table 7-13. Analog Output Commands
© Rice Lake Weighing Systems ● All Rights Reserved
Values
for information about demand print format strings
SCALE1 (default), REMOTE
GROSS (default), NET
0-10V (default), 0-20MA, 4-20MA
FULLSC (default), HOLD, ZEROSC
±9999999.0, 0.0 (default)
±9999999.0, 10000.0 (default)
EDP Commands
Values
Values
51
